7000 851 100 Piston & Ring for DAF and MAN
7000 851 100
The VADEN ORIGINAL 7000 851 100 is a high-strength Piston & Ring kit designed for air brake compressor systems. Featuring an 85,00 mm diameter, 59 mm height, and a 3-ring configuration, it ensures precise fitment and durability. This component is compatible with heavy commercial vehicle systems including DAF, MAN, Mercedes Benz, and Volvo.
| EAN Code | 8699031018249 |
|---|
Compatible OEM Codes
- WABCO 911 501 625 2 911 501 624 2
- MERCEDES BENZ 000 130 53 17 000 130 34 17
- DAF 697442 1283781
- VOLVO 1698686
- MAN 51.54119-6040
Description
This piston and ring set is engineered to provide reliable performance within the air brake compressor system of heavy commercial vehicles. Manufactured with heavy-duty grade materials, the component ensures consistent compression and long-lasting operation under demanding service conditions. The kit includes a piston with an 85,00 mm diameter and three high-strength rings to maintain optimal pneumatic pressure.
7000 851 100 is the OE-equivalent of the WABCO 911 501 624 2 and WABCO 911 501 625 2 piston sets used in DAF XF 460 EURO5, MAN L2000, and Mercedes Benz systems. This part also provides compatibility for various models including Volvo FH 420, Scania, and Renault Trucks, ensuring seamless integration into existing compressor assemblies.
Workshop technicians should ensure that all surfaces are clean and free from debris before installing the new piston and rings. Given the precise dimensions—including a piston height of 59 mm and a pin diameter of 19,05 mm—proper alignment is critical for preventing premature wear. Regular maintenance of the air brake compressor system helps prolong the service life of these high-strength components.
Technical Specifications
| Piston Diameter Ø (mm) | 85,00 |
|---|---|
| Piston Height (mm) | 59 |
| Compression Height (mm) | 33,3 |
| Pin Diameter (mm) | 19,05 |
| Pin Length (mm) | 60 |
| Number of Rings | 3 |
Other OEMs
DAF
- 697442
- 1283781
MAN
- 51541196040
- 51.54119.6040
- 51.54119-6040
MERCEDES BENZ
- A0001305317
- A0001303417
- 0001305317
- 0001303417
- 000.130.5317
- 000.130.53.17
- 000.130.3417
- 000.130.34.17
- 000 130 5317
- 000 130 3417
- 000 130 53 17
- 000 130 34 17
VOLVO
- 1698686
WABCO
- 9115016252
- 9115016242
- 911.501.625.2
- 911.501.624.2
- 911 501 625 2
- 911 501 624 2
