1700 035 001 Renault Trucks Compatible Twin Cylinder Compressor
1700 035 001
Summary
This heavy-duty twin cylinder air compressor is designed for Renault Trucks. Featuring a Ø85.00 mm cylinder bore, 56 mm stroke, and a 636cm³ swept volume, this water-cooled unit ensures efficient air supply for heavy commercial vehicle braking systems. Equivalent to OE Renault Trucks 7420774360 and WABCO 9125120040.
| EAN Code | 8699031049076 |
|---|
Ready to Order
Compatible OEM Codes
-
WABCO
- 912 514 004 0
- 912 514 003 0
- 912 514 001 0
- 912 514 000 0
- 912 512 004 0
-
RENAULT TRUCKS
- 7485003298
- 7421353473
- 7421175029
- 7420774360
Description
What does a twin cylinder compressor do?
This twin cylinder compressor serves as a critical engine-driven component within the air brake system of heavy commercial vehicles. By utilizing two piston-cylinder assemblies, it generates a high volume of compressed air to ensure rapid reservoir filling and consistent pressure for braking operations. Built with high-strength components, this unit is engineered to withstand the rigorous thermal and mechanical demands of heavy-duty service.Compatibility and technical specifications
This specific model is compatible with Renault Trucks and is designed to meet the requirements of WABCO systems. It features a water-cooled design with a water inlet port of M16x1,5 and an outlet port of M16x1,5, ensuring optimal temperature regulation during operation. The unit includes an ESS feature and a water-cooled valve plate to maintain peak efficiency under load.Installation and maintenance guidance
For professional installation, technicians should verify the M26x1,5 air outlet port and the M16x1,5 air inlet port specifications. This through-drive unit has a total weight of 22.6 KG, providing the necessary stability for mounting within the engine compartment. Regular inspection of the water ports and unloader ports is recommended to prevent system leaks.Troubleshooting air supply
Maintaining consistent air pressure is vital for vehicle safety. If the system experiences slow pressure buildup or excessive oil carryover, checking the valve plate and cooling ports is an essential maintenance step to ensure reliable pneumatic performance.OE cross-reference
1700 035 001 (Twin Cylinder Compressor) is the equivalent of the Renault Trucks and WABCO OE numbers. This part directly replaces Renault Trucks OE numbers 7420774360, 7421175029, 7421353473, 7485003298. It also replaces WABCO OE numbers 9125120040, 9125140000, 9125140010, 9125140030, 9125140040.Technical Specifications
| Cylinder Bore | Ø85.00 |
|---|---|
| Stroke | 56 mm |
| Swept Volume | 636cm³ |
| Air Inlet Port | M16x1,5 |
| Air Outlet Port | M26x1,5 |
| Number of Cylinders | 2 |
| Through Drive | OK |
| Air Unloader Port | M16x1,5 |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M16x1,5 |
| Water Outlet Port | M16x1,5 |
| With ESS Feature | OK |
| Water Cooled Valve Plate | OK |
| Weight | 22,6 KG |
Other OEMs
RENAULT TRUCKS
- 7485003298
- 7421353473
- 7421175029
- 7420774360
WABCO
- 9125140040
- 9125140030
- 9125140010
- 9125140000
- 9125120040
- 912.514.004.0
- 912.514.003.0
- 912.514.001.0
- 912.514.000.0
- 912.512.004.0
- 912 514 004 0
- 912 514 003 0
- 912 514 001 0
- 912 514 000 0
- 912 512 004 0
Related Products
Repair Kits
Similar Products
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| RENAULT TRUCKS | |||
| VOLVO | |||
| WABCO |
FAQ
What are the main technical specifications of this unit?
This twin cylinder unit features a Ø85.00 mm bore, a 56 mm stroke, and a total swept volume of 636cm³. It is a water-cooled component weighing 22.6 KG.
Is this compressor compatible with WABCO systems?
Yes, this twin cylinder compressor is designed to be compatible with WABCO systems and specifically fits Renault Trucks vehicles.
What type of cooling does this compressor use?
This is a water-cooled (W) unit featuring specific M16x1,5 water inlet and outlet ports to manage operating temperatures effectively.
How can I identify if my compressor needs replacement?
Technicians should look for symptoms such as slow air reservoir charging or issues with the unloader port (M16x1,5) which may indicate internal wear.
What are the OE reference numbers of this part?
1700 035 001 directly replaces Renault Trucks OE numbers 7420774360, 7421175029, 7421353473, 7485003298. It also replaces WABCO OE numbers 9125120040, 9125140000, 9125140010, 9125140030, 9125140040.
