1100 250 003 Twin Cylinder Air Compressor - MERCEDES BENZ

1100 250 003

Summary

The 1100 250 003 is a high-strength Twin Cylinder Air Compressor designed for heavy commercial vehicle systems. Features include a Ø85.00 mm cylinder diameter, 56 mm stroke, and a 636cm³ swept volume. It is equipped with M26x1,5 air inlet/outlet ports and an M12x1,5 unloader port, utilizing a water-cooled valve plate system for optimal performance.

EAN Code8699031048918
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Compatible OEM Codes

  • WABCO 912 510 101 0
  • MERCEDES BENZ 457 130 37 15

Description

This high-strength component serves as a vital part of the pneumatic system, ensuring consistent air pressure for heavy commercial vehicle braking and suspension functions. The twin cylinder design provides reliable air production under demanding operating conditions.

The 1100 250 003 is the OE equivalent of the MERCEDES BENZ 4571303715 and WABCO 9125101010 air compressor used in MERCEDES BENZ AXOR and AXOR 2 models with OM 457 LA engines. This unit features a water-cooled valve plate and specialized port configurations including M26x1,5 for air flow and M16x1,5 for water cooling to maintain thermal stability.

Technicians should verify the integration of the M26x1,5 air inlet/outlet ports and the M12x1,5 unloader port during installation to ensure seamless system communication. Regular inspection of the water-cooled components is recommended to prevent overheating during extended heavy-duty service cycles.

Check the compatibility list to ensure this part meets your specific engine and vehicle requirements.

Technical Specifications

Cylinder Diameter (mm)Ø85.00
Stroke56 mm
Swept Volume636cm³
Air Inlet PortM26x1,5
Air Outlet PortM26x1,5
Number of Cylinders2
Air Unloader PortM12x1,5
Through DriveOK
With ESS FeatureOK
Water Cooled Valve PlateOK
Water (W) or Air (A) CooledW
Water Inlet PortM16x1,5
Water Outlet PortM16x1,5

Other OEMs

MERCEDES BENZ

  • A4571303715
  • 4571303715
  • 457.130.3715
  • 457.130.37.15
  • 457 130 3715
  • 457 130 37 15

WABCO

  • 9125101010
  • 912.510.101.0
  • 912 510 101 0

Related Products

Repair Kits

Similar Products

Vehicles Used

BrandModelModel TypeEngine
MERCEDES BENZ AXOR 1835 LS OM 457 LA
MERCEDES BENZ AXOR 1840 LS OM 457 LA
MERCEDES BENZ AXOR 1843 LS OM 457 LA
MERCEDES BENZ AXOR 2535 LS OM 457 LA
MERCEDES BENZ AXOR 2540 LS OM 457 LA
MERCEDES BENZ AXOR 2543 LS OM 457 LA
MERCEDES BENZ AXOR 2 1835 LS OM 457 LA
MERCEDES BENZ AXOR 2 1836 LS OM 457 LA
MERCEDES BENZ AXOR 2 1840 LS OM 457 LA
MERCEDES BENZ AXOR 2 1843 LS OM 457 LA
MERCEDES BENZ AXOR 2 2435 LS OM 457 LA
MERCEDES BENZ AXOR 2 2436 LS OM 457 LA
MERCEDES BENZ AXOR 2 2440 LS OM 457 LA
MERCEDES BENZ AXOR 2 2443 LS OM 457 LA
MERCEDES BENZ AXOR 2 2535 L OM 457 LA
MERCEDES BENZ AXOR 2 2535 LS OM 457 LA
MERCEDES BENZ AXOR 2 2535 S OM 457 LA
MERCEDES BENZ AXOR 2 2536 L OM 457 LA
MERCEDES BENZ AXOR 2 2536 LL OM 457 LA
MERCEDES BENZ AXOR 2 2536 LS OM 457 LA
MERCEDES BENZ AXOR 2 2540 L OM 457 LA
MERCEDES BENZ AXOR 2 2540 LS OM 457 LA
MERCEDES BENZ AXOR 2 2543 L OM 457 LA
MERCEDES BENZ AXOR 2 2543 LS OM 457 LA
MERCEDES BENZ AXOR 2 2543 S OM 457 LA
MERCEDES BENZ AXOR 2 2635 B OM 457 LA
MERCEDES BENZ AXOR 2 2635 K OM 457 LA
MERCEDES BENZ AXOR 2 2636 B OM 457 LA
MERCEDES BENZ AXOR 2 2636 K OM 457 LA
MERCEDES BENZ AXOR 2 2640 B OM 457 LA
MERCEDES BENZ AXOR 2 2640 K OM 457 LA
MERCEDES BENZ AXOR 2 2643 B OM 457 LA
MERCEDES BENZ AXOR 2 2643 K OM 457 LA
MERCEDES BENZ AXOR 2 3235 B OM 457 LA
MERCEDES BENZ AXOR 2 3235 K OM 457 LA
MERCEDES BENZ AXOR 2 3236 B OM 457 LA
MERCEDES BENZ AXOR 2 3236 K OM 457 LA
MERCEDES BENZ AXOR 2 3240 OM 457 LA
MERCEDES BENZ AXOR 2 3240 B OM 457 LA
MERCEDES BENZ AXOR 2 3240 K OM 457 LA
MERCEDES BENZ AXOR 2 3243 OM 457 LA
MERCEDES BENZ AXOR 2 3243 B OM 457 LA
MERCEDES BENZ AXOR 2 3243 K OM 457 LA
MERCEDES BENZ AXOR 2 3335 OM 457 LA
MERCEDES BENZ AXOR 2 3335 B OM 457 LA
MERCEDES BENZ AXOR 2 3335 K OM 457 LA
MERCEDES BENZ AXOR 2 3335 S OM 457 LA
MERCEDES BENZ AXOR 2 3336 B OM 457 LA
MERCEDES BENZ AXOR 2 3336 K OM 457 LA
MERCEDES BENZ AXOR 2 3340 OM 457 LA
MERCEDES BENZ AXOR 2 3340 B OM 457 LA
MERCEDES BENZ AXOR 2 3340 K OM 457 LA
MERCEDES BENZ AXOR 2 3340 S OM 457 LA
MERCEDES BENZ AXOR 2 3341 OM 457 LA
MERCEDES BENZ AXOR 2 3341 K OM 457 LA
MERCEDES BENZ AXOR 2 3341 S OM 457 LA
MERCEDES BENZ AXOR 2 3343 OM 457 LA
MERCEDES BENZ AXOR 2 3343 B OM 457 LA
MERCEDES BENZ AXOR 2 3343 K OM 457 LA
MERCEDES BENZ AXOR 2 3343 S OM 457 LA
MERCEDES BENZ AXOR 2 4135 B OM 457 LA
MERCEDES BENZ AXOR 2 4135 K OM 457 LA
MERCEDES BENZ AXOR 2 4136 B OM 457 LA
MERCEDES BENZ AXOR 2 4136 K OM 457 LA
MERCEDES BENZ AXOR 2 4140 B OM 457 LA
MERCEDES BENZ AXOR 2 4140 K OM 457 LA
MERCEDES BENZ AXOR 2 4143 B OM 457 LA
MERCEDES BENZ AXOR 2 4143 K OM 457 LA
MERCEDES BENZ AXOR 2 LL OM 457 LA
MERCEDES BENZ AXOR 2 LLS OM 457 LA
WABCO

FAQ

What are the compatible OEM references for this compressor?
This unit is compatible with MERCEDES BENZ 4571303715 and WABCO 912510101}, {
