1600 120 001 DAF Compatible Twin Cylinder Compressor
1600 120 001
Summary
This water-cooled twin cylinder compressor features a Ø85.00 mm bore, 62/21 mm stroke, and an M33x2 air inlet port. It is designed for high-demand air brake systems in heavy commercial vehicles such as DAF XF105, CF85, and Temsa buses. Equivalent to OE DAF 1674920 and WABCO 9125180000.
| EAN Code | 8699031051031 |
|---|
Ready to Order
Compatible OEM Codes
-
WABCO
- 912 518 004 0
- 912 518 003 0
- 912 518 002 0
- 912 518 001 0
- 912 518 000 0
-
DAF
- 1696197R
- 1696197
- 1687079
- 1681561
- 1674920
Description
What does a twin cylinder compressor do?
A twin cylinder compressor is an engine-driven unit in the air brake system of heavy commercial vehicles that generates compressed air using two piston-cylinder assemblies.Vehicle and engine compatibility
This water-cooled component is engineered to meet the high air consumption demands of heavy-duty vehicles. Featuring a Ø85.00 mm cylinder bore and a 62/21 mm stroke, it provides efficient air production for braking and pneumatic systems. The unit is also equipped with an ESS feature and a water-cooled valve plate to ensure reliable performance under heavy loads.Installation and maintenance
This compressor is compatible with DAF XF105, DAF CF85, and Temsa bus models. It functions seamlessly within systems requiring high air output, such as those found in multi-axle tractor units or touring coaches. The design ensures compatibility with WABCO systems through precise mounting and port specifications.Troubleshooting guidance
For optimal service life, technicians should verify the M33x2 air inlet and M22x1.5 air outlet ports during installation. Regular inspection of the water inlet (M16x1.5) and outlet connections is recommended to prevent leaks in the cooling circuit. Consult your authorized distributor to check the compatibility list.OE cross-reference
1600 120 001 (Twin Cylinder Compressor) is the equivalent of the DAF and WABCO OE numbers. This part directly replaces DAF OE numbers 1674920, 1681561, 1687079, 1696197, 1696197R. It also replaces WABCO OE numbers 9125180000, 9125180010, 9125180020, 9125180030, 9125180040.Technical Specifications
| Cylinder Bore | Ø85.00 |
|---|---|
| Stroke | 62 / 21mm |
| Swept Volume | 352 / 119 cm³ |
| Air Inlet Port | M33x2 |
| Air Outlet Port | M22x1,5 |
| Number of Cylinders | 2 |
| Through Drive | OK |
| Air Unloader Port | M14x1,5 |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M16x1,5 |
| Water Outlet Port | M16x1,5 |
| With ESS Feature | OK |
| Water Cooled Valve Plate | OK |
| Weight | 30,7 KG |
Other OEMs
DAF
- 1696197R
- 1696197
- 1687079
- 1681561
- 1674920
WABCO
- 9125180040
- 9125180030
- 9125180020
- 9125180010
- 9125180000
- 912.518.004.0
- 912.518.003.0
- 912.518.002.0
- 912.518.001.0
- 912.518.000.0
- 912 518 004 0
- 912 518 003 0
- 912 518 002 0
- 912 518 001 0
- 912 518 000 0
Related Products
Repair Kits
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| DAF | |||
| DAF | CF85 | ||
| DAF | XF105 | ||
| Temsa | Otobüs | ||
| WABCO |
FAQ
What is the primary function of this twin cylinder compressor?
It serves as an engine-driven unit that generates compressed air via two piston-cylinder assemblies to meet the high demand of heavy vehicle brake systems.
Which vehicle models is this component compatible with?
This unit is designed for use in DAF XF105, DAF CF85, and Temsa buses, ensuring reliable performance in heavy commercial applications.
How does the water cooling system work on this unit?
The unit utilizes water ports (M16x1.5) for inlet and outlet to manage operating temperatures effectively during high-pressure cycles.
What technical specifications should I verify before installation?
Ensure the bore size (Ø85.00), stroke (62/21mm), and port sizes (M33x2 inlet / M22x1.5 outlet) match your specific requirements.
What are the OE reference numbers of this part?
1600 120 001 directly replaces DAF OE numbers 1674920, 1681561, 1687079, 1696197, 1696197R. It also replaces WABCO OE numbers 9125180000, 9125180010, 9125180020, 9125180030, 9125180040.
