1100 295 001 Mercedes-Benz Compatible Twin Cylinder Compressor
1100 295 001
Summary
High-performance twin cylinder compressor compatible with Mercedes-Benz. Features an 85.00 mm cylinder bore, 56 mm stroke, and water-cooled design for heavy-duty service. Designed to provide high air output for demanding braking systems. Equivalent to OE Mercedes-Benz 9061306415 and WABCO 9125100030.
| EAN Code | 8699031059037 |
|---|
Ready to Order
Compatible OEM Codes
-
MERCEDES BENZ
- 906 130 68 15
- 906 130 67 15
- 906 130 64 15
-
WABCO
- 912 510 005 0
- 912 510 003 0
Description
What does a twin cylinder compressor do?
This twin cylinder compressor serves as a critical component in the air brake system of heavy commercial vehicles, generating the necessary compressed air through two piston-cylinder assemblies. By utilizing two compression strokes, this unit ensures a higher air output than single-cylinder alternatives, facilitating faster reservoir filling. This makes it an essential component for high-demand braking applications in the heavy commercial vehicle sector.Vehicle and engine compatibility
This unit is specifically compatible with Mercedes-Benz vehicles. It is designed to meet the rigorous demands of heavy-duty service, ensuring reliable air pressure delivery for braking and pneumatic systems. The design focuses on durability and consistent performance under high operating pressures.Installation and maintenance
For installation and maintenance, technicians should note the water-cooled configuration with a M14x1.5 water inlet and M16x1.5 water outlet port. The unit features an M26x1.5 air inlet and outlet port and a 21.3 kg weight. Regular inspection of the cooling lines and mounting interface is recommended to ensure optimal system pressure.System integration
When replacing this component, ensure compatibility with existing WABCO systems to maintain integrated pneumatic efficiency.OE cross-reference
1100 295 001 (Twin Cylinder Compressor) is the equivalent of the Mercedes-Benz and WABCO OE numbers. This part directly replaces Mercedes-Benz OE numbers 9061306415, 9061306715, 9061306815. It also replaces WABCO OE numbers 9125100030, 9125100050.Technical Specifications
| Cylinder Bore | Ø85.00 |
|---|---|
| Stroke | 56 mm |
| Swept Volume | 636cm³ |
| Air Inlet Port | M26x1,5 |
| Air Outlet Port | M26x1,5 |
| Number of Cylinders | 2 |
| Through Drive | OK |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M14x1,5 |
| Water Outlet Port | M16x1,5 |
| Water Cooled Valve Plate | OK |
| Weight | 21,3 KG |
Other OEMs
MERCEDES BENZ
- A9061306815
- A9061306715
- A9061306415
- 9061306815
- 9061306715
- 9061306415
- 906.130.6815
- 906.130.68.15
- 906.130.6715
- 906.130.67.15
- 906.130.6415
- 906.130.64.15
- 906 130 6815
- 906 130 6715
- 906 130 6415
- 906 130 68 15
- 906 130 67 15
- 906 130 64 15
WABCO
- 9125100050
- 9125100030
- 912.510.005.0
- 912.510.003.0
- 912 510 005 0
- 912 510 003 0
Related Products
Repair Kits
Similar Products
Compatible Vehicles
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| MERCEDES BENZ | |||
| WABCO |
FAQ
What is the primary function of this twin cylinder compressor?
It generates compressed air via two piston assemblies to ensure rapid reservoir filling and reliable pressure for heavy commercial vehicle braking systems.
Is this unit suitable for Mercedes-Benz trucks?
Yes, this specific twin cylinder compressor is designed to be compatible with Mercedes-Benz vehicles and WABCO systems.
What are the technical specifications regarding cooling?
This is a water-cooled unit featuring an M14x1.5 water inlet port and an M16x1.5 water outlet port.
How can I verify if this part fits my vehicle?
You should check the compatibility list or consult your authorized distributor to ensure the bore size and port types match your requirements.
What are the OE reference numbers of this part?
1100 295 001 directly replaces Mercedes-Benz OE numbers 9061306415, 9061306715, 9061306815. It also replaces WABCO OE numbers 9125100030, 9125100050.
