1100 030 002 MERCEDES BENZ Single Cylinder, Air Compressor

1100 030 002

Summary

●Cylinder Bore: Ø85.00 ●Stroke: 62 mm ●Swept Volume: 352cm³ ●Air Inlet Port: M26x1,5 ●Air Outlet Port: M26x1,5 ●Number of Cylinders: 1 ●Through Drive: ✓ ●Air Unloader Port: M12x1,5 ●Water (W) or Air (A) Cooled: W ●Water Inlet Port: M16x1,5 ●Water Outlet Port: M16x1,5 ●Weight: 16,8 KG

EAN Code8699031048833
Ready to Order
Get Information

Description

The single cylinder air compressor is a critical component in the pneumatic system of heavy commercial vehicles, providing the necessary air pressure for braking and suspension functions. Designed with high-strength components, this unit ensures consistent performance under demanding operating conditions. Its robust construction is engineered to maintain structural integrity during continuous cycles in heavy-duty environments.

1100 030 002 is the OE equivalent of the MERCEDES BENZ 457 130 24 15 and WABCO 412 352 014 0 single cylinder air compressor used in MERCEDES BENZ and EVOBUS vehicles. This technical part is specifically engineered to meet the exact specifications required for seamless integration into the vehicle's air brake system.

For workshop technicians performing maintenance or repairs, this component features a water-cooled design with a water inlet and outlet port size of M16x1,5. The air inlet and outlet ports are equipped with M26x1,5 threading, while the air unloader port uses M12x1,5. Proper installation and regular checks of the cooling system and port seals are essential to ensure optimal pneumatic pressure delivery and long-term reliability.

Technical Specifications

Cylinder BoreØ85.00
Stroke62 mm
Swept Volume352cm³
Air Inlet PortM26x1,5
Air Outlet PortM26x1,5
Number of Cylinders1
Through DriveOK
Air Unloader PortM12x1,5
Water (W) or Air (A) CooledW
Water Inlet PortM16x1,5
Water Outlet PortM16x1,5
With ESS FeatureOK
Water Cooled Valve PlateOK
Weight16,8 KG

Other OEMs

Related Products

Vehicles Used

BrandModelEngine
EVOBUS
MERCEDES BENZ
WABCO

FAQ

What are the compatible OEM numbers for this air compressor?
This product is compatible with MERCEDES BENZ 457 130 24 15 and WABCO 412 325 014 0.
Which vehicle makes can use this single cylinder compressor?
This part is designed for use in MERCEDES BENZ and EVOBUS heavy commercial vehicles.
Does this unit require water cooling?
Yes, this is a water-cooled (W) model featuring M16x1,5 water inlet and outlet ports.
What are the main technical dimensions of the cylinder?
The unit features a cylinder bore of Ø85.00 mm and a stroke of 62 mm with a swept volume of 352cm³.
Is this part compatible with WABCO braking systems?
Yes, it is fully compatible with WABCO systems and meets the requirements for WABCO part number 412 352 014 0.
