2800 060 001 Twin Cylinder, Air Compressor
1022 Visualized

2800 060 001 Twin Cylinder, Air Compressor — MACK

2800 060 001

Summary

●Cylinder Bore: Ø85.00 ●Stroke: 56 mm ●Swept Volume: 636cm³ ●Air Inlet Port: Ø35 ●Air Outlet Port: M26x1,5 ●Number of Cylinders: 2 ●Through Drive: OK ●Air Unloader Port: M16x1,5 ●Water Cooled (W) ●With ESS Feature: OK ●Weight: 22,6 KG

EAN Code8699031070742
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Description

The heavy-duty twin cylinder air compressor is engineered to provide reliable pneumatic pressure within the air brake system. Designed with high-strength components, this unit ensures stable performance under demanding operating conditions. The integrated water-cooled design and specialized valve plate architecture assist in maintaining optimal temperature control during continuous operation.

2800 060 001 is the OE-equivalent of the MACK 21170177 and WABCO 912 542 002 0 air compressor used in VOLVO and MACK heavy commercial vehicle systems. This precision-engineered component ensures seamless integration with existing pneumatic hardware, maintaining the necessary pressure levels for safe braking performance.

Workshop technicians should note the specific technical configuration, including the Ø85.00 cylinder bore and the M26x1,5 air outlet port. Installation requires careful alignment of the through-drive system and verification of the water inlet/outlet ports (M16x1,5) to ensure proper cooling. Regular maintenance of the air unloader port and checking for any leaks in the water-cooling circuit is recommended to prevent system pressure drops.

Technical Specifications

Cylinder BoreØ85.00
Stroke56 mm
Swept Volume636cm³
Air Inlet PortØ35
Air Outlet PortM26x1,5
Number of Cylinders2
Through DriveOK
Air Unloader PortM16x1,5
Water (W) or Air (A) CooledW
Water Inlet PortM16x1,5
Water Outlet PortM16x1,5
With ESS FeatureOK
Water Cooled Valve PlateOK
Weight22,6 KG

Other OEMs

MACK

WABCO

Related Products

Repair Kits

Vehicles Used

BrandModelEngine
MACK
VOLVO
WABCO

FAQ

Which vehicles are compatible with the 2800 060 001 air compressor?
This unit is compatible with MACK and VOLVO heavy commercial vehicles, specifically meeting the requirements for WABCO systems using codes MACK 21170177 and WABCO 912 542 002 0.
What are the technical specifications for the cylinder bore and stroke?
The unit features a cylinder bore of Ø85.00 and a stroke of 56 mm, providing a swept volume of 636cm³ for consistent air production.
Is this an air-cooled or water-cooled air compressor?
This is a water-cooled (W) system featuring a water inlet port (M16x1,5) and a water outlet port (M16x1,5) to manage thermal loads.
Does this part include an ESS feature?
Yes, this twin cylinder air compressor is equipped with the ESS feature to support advanced pneumatic control systems.
What are the port sizes for installation?
The air inlet port is Ø35, the air outlet port is M26x1,5, and the air unloader port is M16x1,5.
