2500 030 003 CUMMINS Single Cylinder, Air Compressor

2500 030 003

Summary

The VADEN ORIGINAL 2500 030 003 is a high-performance single cylinder air compressor designed for heavy commercial vehicle systems. Featuring a cylinder bore of Ø85.00 and a stroke of 56 mm, this water-cooled component is fully compatible with CUMMINS (3103403, 3558163, 4952756) and WABCO (911 153 520 0) systems.

EAN Code8699031068817
Ready to Order
Get Information

Description

The heavy-duty single cylinder air compressor is a critical component in the pneumatic systems of heavy commercial vehicles, ensuring consistent air pressure for braking and suspension functions. This water-cooled unit is engineered with high-strength components to withstand demanding thermal conditions, featuring a Ø85.0 ´bore and a swept volume of 318cm³ to maintain optimal operational-efficiency throughout its service life.

2500 030 003 is the OE-equivalent of the CUMMINS 31034, 3558163, 3680441, 4053825, 4059825, 4069825, and 4952756 air compressors used in CUMMINS M11, N14, and ISM engines, as well as WABCO systems like 911 153 520 0. This component ensures seamless integration within the engine's air supply architecture.

Designed for workshop technicians and fleet managers, this compressor features an M27x2 air outlet port and a M10x1 unloader port. Maintenance should focus on checking the water inlet/outlet ports (3/4" - 16 UNF) and ensuring the water-cooling system is free of obstructions to prevent overheating during long-haul operations. Proper installation of the through-drive mechanism is essential for maintaining system synchronization.

Technical Specifications

Cylinder BoreØ85.00
Stroke56 mm
Swept Volume318cm³
Air Inlet PortØ25
Air Outlet PortM27x2
Number of Cylinders1
Through DriveOK
Air Unloader PortM10x1
Water (W) or Air (A) CooledW
Water Inlet Port3/4? - 16 UNF
Water Outlet Port3/4? - 16 UNF
With ESS FeatureOK
Water Cooled Valve PlateOK
Weight17,4 KG

Other OEMs

Related Products

Vehicles Used

BrandModelEngine
CUMMINS
CUMMINS ISM
CUMMINS M11
CUMMINS N14
WABCO

FAQ

Which vehicle engines is this compressor compatible with?
This air compressor is designed for CUMMINS M11, N14, and ISM engine architectures.
What are the compatible OEM reference numbers?
It is compatible with CUMMINS codes: 3103403, 3558163, 3680441, 4053825, 4059825, 4069825, 4952756 and WABCO code: 911 153 52 much as standard.
Does this unit require water cooling?
Yes, this is a water-cooled single cylinder unit requiring connection to the vehicle's cooling circuit via the inlet/outlet ports.
What are the technical specifications for the ports?
The unit features a Ø25 air inlet port, an M27x2 air outlet port, and an M1M1 unloader port.
Is this part suitable for heavy commercial vehicles?
Yes, it is specifically engineered for heavy commercial vehicle applications such as trucks and buses using CUMMINS or WABCO systems.
