301.03.0077 Complete, Air Dryer Valve
301.03.0077
Summary
●Heater: 24 V ●Port 1: M22x1,5 ●Port 2: M12x1,5 ●Port 21: Ø20,5 ●Pressure: 10 BAR ●Port 22: M16x1,5 VOSS ●Port 23: M22x1,5 ●Port 24: M22x1,5 VOSS ●Port 25: M10x1
| EAN Code | 8699031080482 |
|---|
Ready to Order
Compatible OEM Codes
- KNORR-BREMSE LA 9016 K024635N50 K002738
Description
Meet your Complete, Air Dryer Valve needs on trucks, buses and tractor units with VADEN ORIGINAL 301.03.0077. Compatible with the KNORR-BREMSE (K002738, K024635N50, LA9016) references, this equivalent part is manufactured to OE-quality standards.
Technical Specifications
| Heater | 24 V |
|---|---|
| Port 1 | M22x1,5 |
| Port 2 | M12x1,5 |
| Port 21 | Ø20,5 |
| Pressure | 10 BAR |
| Port 22 | M16x1,5 VOSS |
| Port 23 | M22x1,5 |
| Port 24 | M22x1,5 VOSS |
| Port 25 | M10x1 |
Other OEMs
KNORR-BREMSE
- LA9016
- LA 9016
- K024635N50
- K002738
Related Products
Repair Kits
Products Used in
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| KNORR-BREMSE |
