301.02.0124 Complete, Air Dryer Valve
1167 Visualized

301.02.0124 WABCO Compatible Air Dryer Valve

301.02.0124

Summary

The 301.02.0124 is a high-strength component designed for the brake system. It features a 24 V heater and specific port configurations including Port 1 (M22x1,5), Port 4 (M16x1,5), Port 12 (M22x1,5), Port 21 (M22x1,5), Port 26 (M22x1,5), and Port 25 (M16x1,5), operating at a pressure of 10,5 BAR. This part is fully compatible with IVECO and WABCO systems.

EAN Code8683457012691
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Description

The complete air dryer valve serves as a critical component in the pneumatic brake system of heavy commercial vehicles, ensuring that moisture and contaminants are removed from the compressed air stream. This component is engineered with heavy-duty grade materials to maintain consistent air quality and prevent system-wide failures caused by moisture buildup or freezing in extreme conditions.

301.02.0124 is the OE-equivalent of the WABCO 432 416 002 0 complete air dryer valve used in IVECO vehicle systems. This part is specifically designed to meet the rigorous demands of heavy commercial vehicle braking architectures, ensuring seamless integration with existing pneumatic circuits and maintaining optimal operational pressure.

For workshop technicians and fleet managers, this unit offers a reliable solution for maintaining air system integrity. It features a specialized 24 V heater to prevent freezing during low-temperature operations and includes multiple precision-engineered ports: Port 1 (M22x1,5), Port 4 (M16x1,5), Port 12 (M22x1,5), Port 21 (M22x1,5), Port 26 (M22x1,5), and Port 25 (M16x1,5). Regular inspection of these connections is recommended during routine maintenance to ensure all seals remain intact and the pressure remains at the optimal 10,5 BAR.

Technical Specifications

Heater24 V
Port 1M22x1,5
Port 4M16x1,5
Port 12M22x1,5
Port 21M22x1,5
Pressure10,5 BAR
Port 26M22x1,5
Port 25M16x1,5
Port 3-

Other OEMs

WABCO

Related Products

Repair Kits

Products Used in

Vehicles Used

BrandModelEngine
IVECO
WABCO

FAQ

What are the technical specifications of the 301.02.0124 valve?
The unit operates at a pressure of 10,5 BAR and includes a 24 V heater. It features multiple ports including M22x1,5 and M16x1,5 configurations for precise installation.
Which vehicle brands is this part compatible with?
This product is designed for compatibility with IVECO vehicles and WABCO braking systems to ensure reliable performance in heavy commercial vehicles.
Is this an OE-equivalent part for WABCO?
Yes, the 301.02.0124 is the OE-equivalent for WABCO part number 432 416 002 0 used in heavy-duty braking systems.
Does this part include a heater for cold weather?
Yes, the unit comes equipped with a 24 V heater to prevent moisture-related freezing within the pneumatic system during cold operations.
What are the port sizes for installation?
The ports include Port 1 (M22x1,5), Port 4 (M16x1,5), Port 12 (M22x1,5), Port 21 (M/M), Port 26 (M/M) and Port 25 (M/M) as specified in the technical data.
