301.02.0122 Complete, Air Dryer Valve
976 Visualized

301.02.0122 EVOBUS Complete, Air Dryer Valve

301.02.0122

Summary

This heavy-duty Complete, Air Dryer Valve is engineered for precision and durability in braking systems. It features high-strength components including Port 12 (M12x1,5), Port 21 (M22x1,5), and Port 22 (M16x1,5 VOSS). Designed to operate at a pressure of 12 BAR, it ensures reliable air processing for heavy commercial vehicles.

EAN Code8683457012592
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Description

The technical function of this complete air dryer valve is to remove moisture and contaminants from the compressed air stream within the pneumatic braking system. By utilizing high-strength components and precise port configurations, it maintains consistent air quality to protect downstream pneumatic valves and actuators from damage caused by moisture or debris.

301.02.0122 is the OE-equivalent of the EVOBUS 000 430 87 15 and WABCO 932 400 017 0 complete, air dryer valve used in EVOBUS and WABCO heavy commercial vehicle systems. This component is specifically designed to meet the rigorous demands of heavy-duty transport environments, ensuring that the pneumatic circuit remains dry and functional even under extreme operational pressure.

For workshop technicians, installation requires careful attention to the specific port thread sizes: Port 11 (M22x1,5), Port 12 (M12x1,5), Port 21 (M22x1,5), Port 22 (M16x1,5 VOSS), Port 24 (M22x1,5 VOSS), and Port 4/25 (M10x1 VOSS). Regular inspection of the air dryer assembly is essential during routine maintenance cycles to prevent system contamination and ensure the longevity of the brake system components.

Technical Specifications

Heater-----
Port 12M12x1,5
Port 21M22x1,5
Pressure12 BAR
Port 22M16x1,5 VOSS
Port 11M22x1,5
Port 24M22x1,5 VOSS
Port 4/25M10x1 VOSS
Port 23-

Other OEMs

EVOBUS

  • 000 430 87 15
  • A0004308715

WABCO

  • 932 400 017 0
  • 9324000170

Related Products

Repair Kits

Vehicles Used

BrandModelEngine
EVOBUS
WABCO

FAQ

What are the compatible OEM-equivalent codes for this part?
This component is a direct replacement for EVOBUS 000 430 87 15 and WABCO 932 400 017 0.
What is the operating pressure for this air dryer valve?
The unit is designed to operate within a standard pressure of 12 BAR for heavy-duty pneumatic systems.
Which vehicle makes is this part compatible with?
It is compatible with systems used by EVOBUS and WABCO in heavy commercial vehicles.
What are the specific port specifications for installation?
The ports include M12x1,5 (Port 12), M22x1,5 (Port 21/Port 11), M16x1,5 VOSS (Port 22), and M10x1 VOSS (Port 4/25).
Is this part suitable for heavy commercial vehicle brake systems?
Yes, it is specifically engineered as a complete air dryer valve for heavy-duty braking applications.
