301.02.0121 DAF Complete, Air Dryer Valve
301.02.0121
Summary
●Heater: 24 V ●Port 12: M12x1,5 ●Port 21: M22x1,5 ●Pressure: 12,5 BAR ●Port 22: M16x1,5 VOSS ●Port 11: M22x1,5 ●Port 24: M22x1,5 VOSS ●Port 4/25: M10x1 VOSS
| EAN Code | 8683457012585 |
|---|
Ready to Order
Compatible OEM Codes
- WABCO 932 400 021 0
- VDL 30016600
- DAF 1527583
Description
The air drying process is critical for maintaining the pneumatic integrity of heavy commercial vehicle brake systems. This complete air dryer valve assembly is engineered to manage moisture removal and pressure regulation effectively, ensuring long-term reliability in demanding environments.
This component is a high-strength part designed to be compatible with DAF (1527583), VDL (30016600), and WABCO (9324000210) systems. The 301.02.0121 is the OE equivalent of the DAF 1527583 product used in heavy-duty commercial vehicles. It features a 24 V heater and specialized port configurations including M22x1,5 and M16x1,5 VOSS connections to ensure precise fitment and airtight performance.
For workshop technicians, this unit provides a streamlined replacement solution for maintaining air system pressure stability. The integration of high-strength components ensures the valve operates reliably under a constant pressure of 12,5 BAR. Regular inspection of the ports and moisture filtration efficiency is recommended during standard maintenance intervals to prevent system contamination.
Ensuring the correct port sizing and electrical compatibility is essential for seamless installation during service.
This component is a high-strength part designed to be compatible with DAF (1527583), VDL (30016600), and WABCO (9324000210) systems. The 301.02.0121 is the OE equivalent of the DAF 1527583 product used in heavy-duty commercial vehicles. It features a 24 V heater and specialized port configurations including M22x1,5 and M16x1,5 VOSS connections to ensure precise fitment and airtight performance.
For workshop technicians, this unit provides a streamlined replacement solution for maintaining air system pressure stability. The integration of high-strength components ensures the valve operates reliably under a constant pressure of 12,5 BAR. Regular inspection of the ports and moisture filtration efficiency is recommended during standard maintenance intervals to prevent system contamination.
Ensuring the correct port sizing and electrical compatibility is essential for seamless installation during service.
Technical Specifications
| Heater | 24 V |
|---|---|
| Port 12 | M12x1,5 |
| Port 21 | M22x1,5 |
| Pressure | 12,5 BAR |
| Port 22 | M16x1,5 VOSS |
| Port 11 | M22x1,5 |
| Port 23 | - |
| Port 24 | M22x1,5 VOSS |
| Port 4/25 | M10x1 VOSS |
Other OEMs
DAF
- 1527583
VDL
- 30016600
WABCO
- 9324000210
- 932 400 021 0
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| DAF | |||
| VDL | |||
| WABCO |
FAQ
What are the primary OEM cross-references for this air dryer valve?
This product is compatible with the following OEM references: DAF 1527583, VDL 30016600, and WABCO 9324000210.
What are the electrical and pressure specifications?
The unit is designed for a 24 V heater system and operates at a standard pressure of 12,5 BAR.
Which vehicle makes are compatible with this part?
This component is engineered for compatibility with DAF and VDL heavy commercial vehicle systems.
What type of port connections does this unit use?
The assembly includes various ports such as M12x1,5, M22x1,5, and M16x1,5 VOSS to ensure precise integration into the pneumatic circuit.
Is this part suitable for heavy-duty commercial applications?
Yes, it is designed as a high-strength component specifically for heavy commercial vehicle brake systems requiring reliable moisture control.
