301.02.0121 Complete, Air Dryer Valve
301.02.0121
Summary
●Heater: 24 V ●Port 12: M12x1,5 ●Port 21: M22x1,5 ●Pressure: 12,5 BAR ●Port 22: M16x1,5 VOSS ●Port 11: M22x1,5 ●Port 23: - ●Port 24: M22x1,5 VOSS ●Port 4/25: M10x1 VOSS
| EAN Code | 8683457012585 |
|---|
Ready to Order
Compatible OEM Codes
- WABCO 932 400 021 0
- VDL 30016600
- DAF 1527583
Description
VADEN ORIGINAL 301.02.0121 is the OE-quality equivalent of the original WABCO (9324000210), VDL (30016600), DAF (1527583) references in the Complete, Air Dryer Valve group. It is produced to fit the original dimensions and mounting points exactly and runs trouble-free after installation.
Technical Specifications
| Heater | 24 V |
|---|---|
| Port 12 | M12x1,5 |
| Port 21 | M22x1,5 |
| Pressure | 12,5 BAR |
| Port 22 | M16x1,5 VOSS |
| Port 11 | M22x1,5 |
| Port 23 | - |
| Port 24 | M22x1,5 VOSS |
| Port 4/25 | M10x1 VOSS |
Other OEMs
DAF
- 1527583
VDL
- 30016600
WABCO
- 9324000210
- 932 400 021 0
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| DAF | |||
| VDL | |||
| WABCO |
