301.02.0119 MERCEDES BENZ Complete, Air Dryer Valve
301.02.0119
Summary
This high-strength Complete, Air Dryer Valve is engineered for heavy commercial vehicle brake systems. Featuring a 24 V heater and 11,5 BAR pressure capacity, it includes specific ports: Port 21 (M22x1,5), Port 22 (M16x1,5 VOSS), Port 11 (M10x1 VOSS), Port 23 (M16x1,5), Port 24 (M22x1,5 VOSS), and Port 4/25 (M12x1,5). Compatible with MERCEDES BENZ and WABCO systems.
| EAN Code | 8683457012561 |
|---|
Ready to Order
Compatible OEM Codes
- WABCO 932 400 016 0
- MERCEDES BENZ 002 431 57 15
Description
Maintaining a reliable pneumatic system is essential for the longevity of heavy commercial vehicle brake components. This complete air dryer valve is designed to effectively manage moisture and pressure within the braking circuit, ensuring consistent performance under rigorous operational conditions.
The 301.02.0119 is the OE equivalent of the MERCEDES BENZ 0024315715 and WABCO 9324000160 components used in heavy-duty braking systems. It is specifically engineered to meet the strict requirements of MERCEDES BENZ and WABCO hardware configurations, providing a precise fit for professional workshop applications.
Technical specifications include a 24 V heater and a pressure rating of 11,5 BAR. The unit features various port configurations such as M22x1,5 at Port 21 and M22x1,5 VOSS at Port 24 to ensure secure connections. Technicians should verify all port dimensions and pressure compatibility before installation to maintain optimal system integrity.
Regular maintenance of the air dryer assembly helps prevent moisture accumulation in the pneumatic lines, protecting downstream components from corrosion and air system failures.
The 301.02.0119 is the OE equivalent of the MERCEDES BENZ 0024315715 and WABCO 9324000160 components used in heavy-duty braking systems. It is specifically engineered to meet the strict requirements of MERCEDES BENZ and WABCO hardware configurations, providing a precise fit for professional workshop applications.
Technical specifications include a 24 V heater and a pressure rating of 11,5 BAR. The unit features various port configurations such as M22x1,5 at Port 21 and M22x1,5 VOSS at Port 24 to ensure secure connections. Technicians should verify all port dimensions and pressure compatibility before installation to maintain optimal system integrity.
Regular maintenance of the air dryer assembly helps prevent moisture accumulation in the pneumatic lines, protecting downstream components from corrosion and air system failures.
Technical Specifications
| Heater | 24 V |
|---|---|
| Port 21 | M22x1,5 |
| Pressure | 11,5 BAR |
| Port 22 | M16x1,5 VOSS |
| Port 11 | M10x1 VOSS |
| Port 23 | M16x1,5 |
| Port 24 | M22x1,5 VOSS |
| Port 4/25 | M12x1,5 |
Other OEMs
MERCEDES BENZ
- A0024315715
- 002 431 57 15
WABCO
- 9324000160
- 932 400 016 0
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| MERCEDES BENZ | |||
| WABCO |
FAQ
What are the compatible OEM cross-references for this part?
This product is compatible with the following OEM numbers: 0024315715, 9324000160.
Which vehicle brands is this air dryer valve compatible with?
This component is designed for use with MERCEDES BENZ and WABCO systems in heavy commercial vehicles.
What are the technical port specifications for this unit?
The unit features Port 21 (M22x1,5), Port 22 (M16x1,5 VOSS), Port 11 (M10x1 VOSS), Port 23 (M16x1,5), Port 24 (M22x1,5 VOSS), and Port 4/25 (M12x1,5).
Does this air dryer valve include a heater?
Yes, this model is equipped with a 24 V heater to ensure optimal performance in various temperature conditions.
What is the maximum operating pressure for this component?
The device is designed to operate at a pressure of up to 11,5 BAR within the braking system.
