301.02.0110 WABCO Complete, Air Dryer Valve
301.02.0110
The 301.02.0110 is a high-strength air dryer valve assembly designed for heavy commercial vehicle brake systems. It features a 12 V heater, Port 1 (1/2"-14 NPTF), Port 21 (1/2"-14 NPTF), and Port 4/23 (1/4"-18 NPTF), operating within a pressure range of 7,9 to 9 BAR.
| EAN Code | 8683457009684 |
|---|
Description
The heavy-duty grade materials used in this air dryer valve ensure reliable performance within the pneumatic braking system of heavy commercial vehicles. This component is essential for maintaining optimal air quality and pressure regulation, providing long-lasting durability under demanding operational conditions.
301.02.0110 is the OE-equivalent of the WABCO 432 413 007 0 complete, air dryer valve used in SCANIA and MACK vehicle systems. This part is also fully compatible with Volvo and other major heavy vehicle brands requiring high-strength pneumatic components.
Designed for professional workshop technicians, this assembly features specific port dimensions including Port 1 and Port 21 at 1/2"-14 NPTF and Port 4/23 at 1/4"-18 NPTF. It operates with a 12 V heater and maintains a stable working pressure between 7,9 and 9 BAR to ensure consistent system-wide performance.
Regular maintenance and checking of the air dryer assembly are recommended to prevent moisture buildup within the pneumatic lines, ensuring the longevity of the entire brake system.
Technical Specifications
| Heater | 12 V |
|---|---|
| Port 1 | 1/2"-14 NPTF |
| Port 21 | 1/2"-14 NPTF |
| Pressure | 7,9 to 9 BAR |
| Port 4/23 | 1/4"-18 NPTF |
Other OEMs
SCANIA
WABCO
Vehicles Used
| Brand | Model | Engine |
|---|---|---|
| MACK | ||
| SCANIA | ||
| VOLVO | ||
| WABCO |
