301.02.0100 Complete, Air Dryer Valve — WABCO
301.02.0100
Summary
●Heater: 24 V ●Port 1: M22x1,5 ●Port 21: M22x1,5 VOSS ●Pressure: 11 BAR ●Port 4/23: M12x1,5. This high-strength component is an OE equivalent for WABCO systems.
| EAN Code | 8683457004405 |
|---|
Ready to Order
Compatible OEM Codes
- WABCO 432 415 050 0
Description
This complete air dryer valve is engineered to maintain optimal pneumatic system performance within heavy commercial vehicle brake systems. Designed for high-strength operation, the component ensures consistent pressure regulation and moisture separation to protect downstream components from contamination.
The 301.02.0100 is the OE equivalent of the WABCO 4324150500 used in heavy-duty vehicle systems. It features a 24 V heater and specific port configurations including M22x1,5 and M12x1,5 connections to ensure precise integration with existing hardware. This product is compatible with WABCO systems.
For workshop technicians performing routine maintenance, this valve provides a reliable solution for maintaining air quality in the braking circuit. It is essential to verify the port sizes and pressure ratings, such as the 11 BAR operating standard, before installation to ensure seamless system compatibility.
Regular inspection of the air dryer assembly helps prevent moisture accumulation and maintains system integrity. Ensure that all connections are secure and that the electrical heater functionality is checked during scheduled service intervals.
The 301.02.0100 is the OE equivalent of the WABCO 4324150500 used in heavy-duty vehicle systems. It features a 24 V heater and specific port configurations including M22x1,5 and M12x1,5 connections to ensure precise integration with existing hardware. This product is compatible with WABCO systems.
For workshop technicians performing routine maintenance, this valve provides a reliable solution for maintaining air quality in the braking circuit. It is essential to verify the port sizes and pressure ratings, such as the 11 BAR operating standard, before installation to ensure seamless system compatibility.
Regular inspection of the air dryer assembly helps prevent moisture accumulation and maintains system integrity. Ensure that all connections are secure and that the electrical heater functionality is checked during scheduled service intervals.
Technical Specifications
| Heater | 24 V |
|---|---|
| Port 1 | M22x1,5 |
| Port 21 | M22x1,5 VOSS |
| Pressure | 11 BAR |
| Port 4/23 | M12x1,5 |
Other OEMs
WABCO
- 4324150500
- 432.415.050.0
- 432 415 050 0
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| WABCO |
FAQ
What are the primary technical specifications of this air dryer valve?
The component features a 24 V heater and includes Port 1 (M22x1,5), Port 21 (M22x1,5 VOSS), and Port 4/23 (M12x1,5) for precise connectivity.
Which OEM brands is this part compatible with?
This part is compatible with WABCO systems and specifically matches the OE reference 4324150500.
What is the operating pressure for this component?
The unit is designed to operate within a standard pressure of 11 BAR to ensure reliable pneumatic performance.
Is this part suitable for heavy-duty vehicle brake systems?
Yes, it is a high-strength component designed specifically for the demanding environments of heavy commercial vehicle brake systems.
How can I verify if this part fits my current system?
Please check your technical manual for the required port sizes (M22x1,5 and M12x1,5) and confirm compatibility with the WABCO 4324150500 reference.
