301.02.0076 Complete, Air Dryer Valve
937 Visualized

301.02.0076 Complete, Air Dryer Valve — SCANIA

301.02.0076

Summary

●Heater: 24 V ●Port 1: M22x1,5 ●Port 21: M22x1,5 ●Pressure: 12,5 BAR ●Port 22: M12x1,5 ●Port 4/23: M12x1,5. This high-strength component ensures reliable pneumatic regulation in heavy-duty brake systems.

EAN Code8699031086798
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Description

The complete air dryer valve is a critical component designed to manage air pressure and remove moisture from the pneumatic system to ensure optimal braking performance. This part is engineered with heavy-duty grade materials to withstand high-pressure environments and maintain system stability during long-haul transport operations.

301.02.0076 is the OE-equivalent of the WABCO 432 410 076 0 complete air dryer valve used in DAF, IVECO, and SCANIA heavy commercial vehicles. This component is specifically designed to meet the rigorous standards of modern braking systems by providing consistent pressure regulation across various operating conditions.

For workshop technicians, this assembly features a 24 V heater and specific port configurations including M22x1,5 and M12x1,5 threads to ensure precise fitment. Regular inspection of the air dryer system and its connections is recommended to maintain optimal pneumatic function and prevent moisture buildup in the brake lines.

The installation process requires attention to the port sizes and the electrical connection for the heater to ensure full system functionality. Utilizing high-strength components like this one helps in reducing unscheduled downtime caused by pneumatic irregularities or moisture intrusion.

Technical Specifications

Heater24 V
Port 1M22x1,5
Port 21M22x1,5
Pressure12,5 BAR
Port 22M12x1,5
Port 4/23M12x1,5

Other OEMs

DAF

  • 1518676

IVECO

  • 41031476

SCANIA

  • 390854

WABCO

  • 432 410 076 0
  • 432.410.076.0
  • 4324100760

Related Products

Repair Kits

Vehicles Used

BrandModelEngine
DAF
IVECO
SCANIA
WABCO

FAQ

Which vehicle brands are compatible with this air dryer valve?
This product is compatible with DAF (1518676), IVECO (41031476), SCANIA (390854), and WABCO (432 410 076 0) systems.
What are the technical specifications for the ports?
The unit features Port 1 and Port 21 at M22x1,5, while Port 22 and Port 4/23 use M12x1,5 threading.
Does this component include a heater for cold weather operations?
Yes, this complete air dryer valve is equipped with a 24 V heater to ensure reliable performance in diverse climates.
Is this part suitable for heavy-duty trucks?
Yes, it is designed specifically for heavy commercial vehicles like DAF, IVECO, and SCANIA that require high-strength pneumatic components.
What is the operating pressure for this valve?
The component is engineered to operate at a pressure of 12,5 BAR within the brake system.
