301.02.0063 MERCEDES BENZ Complete, Air Dryer Valve
301.02.0063
●Heater: 24 V ●Port 1: M22x1,5 VOSS ●Port 21: M22x1,5 VOSS ●Pressure: 10 BAR ●Port 22: M16x1,5 VOSS ●Port 4/23: -
| EAN Code | 8699031075662 |
|---|
Description
The technical function of this air dryer component is to ensure the continuous removal of moisture and contaminants from the pneumatic braking system, maintaining optimal air quality for heavy commercial vehicles. Designed with high-strength components, it provides reliable service in demanding environments.
301.02.0063 is the OE-equivalent of the MERCEDES BENZ 001 431 62 15 complete, air dryer valve used in MERCEDES BENZ and SCANIA vehicles. This part also meets the technical requirements for WABCO systems (432 410 069 0) and SCANIA (390854) specifications, ensuring seamless integration into the braking architecture.
Workshop technicians should note the specific port configurations: Port 1 and Port 21 utilize M22x1,5 VOSS connections, while Port 22 features an M16x1,5 VOSS thread. The unit operates at a pressure of 10 BAR and includes a 24 V heater to prevent freezing during cold-weather operations. Regular inspection of the pneumatic lines and seals is recommended during routine heavy vehicle maintenance to ensure long-term system stability.
Technical Specifications
| Heater | 24 V |
|---|---|
| Port 1 | M22x1,5 VOSS |
| Port 21 | M22x1,5 VOSS |
| Pressure | 10 BAR |
| Port 22 | M16x1,5 VOSS |
| Port 4/23 | - |
Other OEMs
MERCEDES BENZ
- 001 431 62 15
- 001 431 6215
- 001.431.62.15
- 001.431.6215
- 0014316215
- A0014316215
SCANIA
- 390854
WABCO
- 432 410 069 0
- 432.410.069.0
- 4324100690
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Engine |
|---|---|---|
| ALEXANDER DENNIS | ||
| EVOBUS | ||
| MERCEDES BENZ | ||
| SCANIA | ||
| WABCO |
