301.02.0056 SCANIA Complete, Air Dryer Valve
301.02.0056
Summary
●Port 1: M22x1,5 ●Port 21: M12x1,5 ●Pressure: 11,2 BAR ●Port 22: M12x1,5 ●Port 4/23: M12x1,5 ●Heater: 24 V
| EAN Code | 8699031075587 |
|---|
Ready to Order
Compatible OEM Codes
- WABCO 432 410 004 0
- SCANIA 390854
Description
This heavy-duty grade component is designed to ensure optimal air filtration and moisture control within the braking system. The Complete, Air Dryer Valve functions as a critical element in maintaining pneumatic stability and preventing system contamination under demanding conditions.
The 301.02.0056 is the OE equivalent of the SCANIA 390854 and WABCO 4324100040 components used in heavy commercial vehicle braking systems. It features a specialized 24V heater and precise port configurations including M22x1,5 and M12x1,5 to ensure seamless integration with existing hardware.
Technicians should verify the pressure rating of 11,2 BAR and port dimensions during installation to ensure perfect fitment. Regular inspection of the air dryer assembly is recommended to maintain optimal braking performance and prevent moisture-related issues in the pneumatic circuit.
The 301.02.0056 is the OE equivalent of the SCANIA 390854 and WABCO 4324100040 components used in heavy commercial vehicle braking systems. It features a specialized 24V heater and precise port configurations including M22x1,5 and M12x1,5 to ensure seamless integration with existing hardware.
Technicians should verify the pressure rating of 11,2 BAR and port dimensions during installation to ensure perfect fitment. Regular inspection of the air dryer assembly is recommended to maintain optimal braking performance and prevent moisture-related issues in the pneumatic circuit.
Technical Specifications
| Port 1 | M22x1,5 |
|---|---|
| Port 21 | M12x1,5 |
| Pressure | 11,2 BAR |
| Port 22 | M12x1,5 |
| Port 4/23 | M12x1,5 |
| Heater | 24 V |
Other OEMs
SCANIA
- 390854
WABCO
- 4324100040
- 432.410.004.0
- 432 410 004 0
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| SCANIA | |||
| WABCO |
FAQ
What are the compatible OEM cross-references for this part?
This product is compatible with the following OE numbers: SCANIA 390854, WABCO 4324100040.
What is the technical specification for the heater voltage?
This complete air dryer valve is designed for systems requiring a 24 V heater.
Which vehicle systems is this part compatible with?
It is engineered for heavy commercial vehicle brake systems, specifically compatible with SCANIA and WABCO hardware.
What are the port dimensions for this air dryer valve?
The unit features Port 1 (M22x1,5), Port 21 (M12x1,5), Port 22 (M12x1,5), and Port 4/23 (M12x1,5).
What is the operating pressure of this component?
The component is designed to operate at a pressure of 11,2 BAR.
