301.02.0034 Complete, Air Dryer Valve
2290 Visualized

301.02.0034 IVECO Complete, Air Dryer Valve

301.02.0034

Summary

●Heater: ----- ●Port 1: M22x1,5 ●Port 21: M22x1,5 ●Pressure: 7,8 BAR ●Port 22: M12x1,5 ●Port 4/23: -

EAN Code8699031075273
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Description

The complete air dryer valve is a critical component within the pneumatic braking system, ensuring the removal of moisture and contaminants to maintain optimal air quality and system reliability. This part is engineered with high-strength components to withstand the rigorous demands of heavy commercial vehicle operations.

301.02.0034 is the OE-equivalent complete, air dryer valve used in DAF (1505964), IVECO (42086180, 42086182, 42086184, 4212429, 42125016), SCANIA (390854), and WABCO (432 410 031 0) systems. It provides precise pressure regulation and maintains consistent performance across various heavy-duty applications.

Designed for workshop technicians and fleet managers, this unit features specific port configurations including M22x1,5 for Port 1 and Port 21, and M12x1,5 for Port 22. Regular inspection of the pneumatic lines and ensuring compatibility with the existing pressure settings of 7,8 BAR is recommended during routine maintenance to ensure long-term system integrity.

Technical Specifications

Heater-----
Port 1M22x1,5
Port 21M22x1,5
Pressure7,8 BAR
Port 22M12x1,5
Port 4/23-

Other OEMs

DAF

  • 1505964

IVECO

  • 42086180
  • 42086182
  • 42086184
  • 4212429
  • 42125016

SCANIA

  • 390854

WABCO

  • 432 410 031 0
  • 432.410.031.0
  • 4324100310

Related Products

Repair Kits

Vehicles Used

BrandModelEngine
DAF
IVECO
SCANIA
WABCO

FAQ

What are the compatible OEM numbers for this air dryer valve?
This part is compatible with OEM numbers: 1505964 (DAF), 42086180, 42086182, 42 brother 6184, 4212429, 42125016 (IVECO), 390854 (SCANIA), and 432 410 031 0 (WABCO).
What is the operating pressure for this component?
The unit is designed to operate at a standard pressure of 7,8 BAR within the pneumatic braking system.
Which vehicle types can use this part?
This component is specifically designed for heavy commercial vehicles such as trucks and buses from manufacturers like IVECO, SCANIA, and DAF.
What are the technical port specifications?
The technical specifications include Port 1: M22x1,5; Port 21: M22x1,5; and Port 22: M12x1,5.
Is this part suitable for heavy-duty truck systems?
Yes, it is built with high-strength components to meet the requirements of heavy-duty commercial vehicle brake systems.
