301.02.0016 Complete, Air Dryer Valve — DAF / MAN
301.02.0016
●Port 1: M22x1,5 ●Port 21: M22x1,5 ●Port 22: M16x1,5 ●Pressure: 10 BAR ●System: Brake System - Air Dryer Valve
| EAN Code | 8699031086668 |
|---|
Description
The technical function of this complete air dryer valve is to ensure the removal of moisture and impurities from the compressed air system, maintaining optimal pressure and preventing component corrosion. Designed for heavy-duty grade materials, this component provides reliable pneumatic regulation within the brake system of heavy commercial vehicles.
301.02.0016 is the OE-equivalent of the WABCO 432 410 117 0 complete air dryer valve used in DAF and MAN vehicles. This part is also fully compatible with several MAN-specific references including 81.52102-6098, 81.52102-6100, and 81.52102-6106, ensuring a seamless fit for heavy-duty transport applications.
Workshop technicians should verify the port configurations during installation to ensure optimal performance. This unit features a primary port of M22x1,5 and a secondary port of M16x1,5, operating at a standard pressure of 10 BAR. Proper assembly and routine maintenance of the air filtration components are essential for maintaining vehicle safety and system longevity.
Technical Specifications
| Heater | ----- |
|---|---|
| Port 1 | M22x1,5 |
| Port 21 | M22x1,5 |
| Pressure | 10 BAR |
| Port 22 | M16x1,5 |
| Port 4/23 | - |
Other OEMs
DAF
- 1517969
MAN
- 81.52102-6098
- 81.52102-6100
- 81.52102-6106
- 81.52102.6098
- 81.52102.6100
- 81.52102.6106
- 81521026098
- 81521026100
- 81521026106
WABCO
- 432 410 117 0
- 432.410.117.0
- 4324101170
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Engine |
|---|---|---|
| DAF | ||
| MAN | ||
| MAN | NEOPLAN | |
| NEOPLAN | ||
| WABCO |
