301.02.0001 MACK Complete, Air Dryer Valve
301.02.0001
●Heater: 24 V ●Port 1: M22x1,5 ●Port 21: M22x1,5 ●Pressure: 8,5 BAR ●Port 22: M12x1,5 ●Port 4/23: M12x1,5
| EAN Code | 8699031062297 |
|---|
Description
The high-strength component designed for pneumatic system regulation is essential for maintaining optimal air quality in heavy-duty braking systems. This complete air dryer valve assembly provides reliable moisture separation and pressure regulation to ensure the longevity of downstream pneumatic components in various heavy commercial vehicle applications.
301.02.0001 is the OE-equivalent of the WABCO 432 410 007 0 complete air dryer valve used in MACK, SCANIA, VOLVO, DAF, IVECO, and LIEBHERR systems. This part is engineered to meet strict technical standards for high-pressure environments, ensuring seamless integration with original braking-pneumatic hardware.
Workshop technicians should note the specific port configurations: Port 1 and Port 21 utilize M22x1,5 threading, while Port 22 and Port 4/23 are designed with M12x1,5 connections. The unit operates with a 24 V heater and is rated for a working pressure of 8,5 BAR. Regular inspection of the filter elements and ensuring airtight connections at the specified ports is recommended during routine maintenance to prevent system contamination.
Technical Specifications
| Heater | 24 V |
|---|---|
| Port 1 | M22x1,5 |
| Port 21 | M22x1,5 |
| Pressure | 8,5 BAR |
| Port 22 | M12x1,5 |
| Port 4/23 | M12x1,5 |
Other OEMs
ALEXANDER DENNIS
- DP002122
DAF
- 1517963
IVECO
- 981819
LIEBHERR
- 502657308
MACK
- 6300-4324100070
SCANIA
- 390854
VOLVO
- WAB4324100070
WABCO
- 432 410 007 0
- 432.410.007.0
- 4324100070
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Engine |
|---|---|---|
| ALEXANDER DENNIS | ||
| DAEWOO | ||
| DAF | ||
| IRISBUS | ||
| IVECO | ||
| KING LONG | ||
| LIEBHERR | ||
| MACK | ||
| MERCEDES BENZ | ||
| PACCAR | ||
| SCANIA | ||
| VDL | ||
| VOLVO | ||
| WABCO |
