51541007204 MAN Single Cylinder, Air Compressor
1200 210 001
●Cylinder Bore: Ø92.00 ●Stroke: 54 mm ●Swept Volume: 360cm³ ●Air Inlet Port: M26x1,5 ●Air Outlet Port: M26x1,5 ●Number of Cylinders: 1 ●Through Drive: ✓ ●Water (W) or Air (A) Cooled: W ●Water Inlet Port: M16x1,5 ●Water Outlet Port: M16x1,5 ●Water Cooled Valve Plate: ✓ ●Weight: 20,7 KG
| EAN Code | 8699031061078 |
|---|
Description
The single cylinder air compressor is a vital component within the pneumatic braking system, ensuring consistent air pressure for heavy-duty operations. This unit is engineered with high-strength components to maintain reliable performance under demanding thermal and mechanical stress within the engine compartment.
51541007204 is the OE-equivalent single cylinder air compressor used in MAN LIONS CITY A 20, TGA 18.310, and various other MAN heavy commercial vehicle models. This part is fully compatible with the MAN 51.54100-7204 reference system, ensuring seamless integration with existing pneumatic architectures in trucks and buses.
Designed for workshop technicians and fleet managers, this compressor features a water-cooled system (W) to manage operating temperatures efficiently. The assembly includes a water-cooled valve plate and specific port dimensions (Air: M26x1,5; Water: M16x1,5) to facilitate precise installation during routine maintenance or system overhauls.
Regular inspection of the air inlet and outlet ports is recommended to ensure no debris interferes with the high-strength components. For optimal performance in heavy commercial vehicle applications, always verify that the water cooling connections are secure and free from obstructions.
Technical Specifications
| Cylinder Bore | Ø92.00 |
|---|---|
| Stroke | 54 mm |
| Swept Volume | 360cm³ |
| Air Inlet Port | M26x1,5 |
| Air Outlet Port | M26x1,5 |
| Number of Cylinders | 1 |
| Through Drive | OK |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M16x1,5 |
| Water Outlet Port | M16x1,5 |
| Water Cooled Valve Plate | OK |
| Weight | 20,7 KG |
