303.06.0112 WABCO Compatible ALB Load Sensing Valve

303.06.0112

Summary

The 303.06.0112 is a high-precision ALB Load Sensing Valve designed for heavy commercial vehicle brake systems. It features specific pressure settings: Empty Pressure Port 41/42 at 1,75 BAR, Empty Pressure Port 2 at 4,4 BAR, Full Pressure Port 2 at 7,7 BAR, and Full Pressure Port 41/42 at 6,3 BAR. Port configurations include Port 1 (M22x1,5), Port 2 (M16x1,5 x2), and Port 4 (M16x1,50).

EAN Code8683457051294
Ready to Order
Get Information

Description

The complete ALB load sensing valve serves a critical function in regulating brake pressure based on the vehicle's load weight, ensuring optimal braking performance and stability. This component is engineered with heavy-duty grade materials to withstand the rigorous pneumatic requirements of the heavy commercial vehicle brake system.

303.06.0112 is the OE-equivalent of the WABCO 475 711 145 0 and VOLVO 9958760 load sensing valves used in heavy-duty truck systems. This unit provides precise pressure modulation through its specialized ports, including M22x1,5 and M16x1,5 connections, to maintain consistent braking force across varying load conditions.

For workshop technicians performing maintenance or system overhauls, this part offers direct compatibility with WABCO and VOLVO pneumatic architectures. Proper installation ensures that the pressure thresholds—specifically the 1,75 BAR empty pressure and the 7,7 BAR full pressure specifications—are met accurately to maintain vehicle safety and regulatory compliance.

Maintaining the integrity of the brake system requires high-strength components that can handle fluctuating pressure cycles without degradation. This valve is designed to provide a reliable solution for fleet managers looking to maintain original equipment standards during routine service or technical repairs.

Technical Specifications

Empty Pressure Port 41/421,75 BAR
Empty Pressure Port 24,4 BAR
Full Pressure Port 27,7 BAR
Full Pressure Port 41/426,3 BAR
Port 1M22x1,5
Port 2M16x1,5(x2)
Port 4M16x1,50

Other OEMs

VOLVO

  • 9958760

WABCO

  • 475 711 145 0
  • 4757111450

Related Products

Vehicles Used

BrandModelEngine
VOLVO
WABCO

FAQ

What are the pressure specifications for this load sensing valve?
The valve features an Empty Pressure Port 41/42 of 1,75 BAR and a Full Pressure Port 41/42 of 6,3 BAR, ensuring accurate load-based braking.
Which OEM numbers is this part compatible with?
This product is compatible with WABCO 475 711 145 0 and VOLVO 9958760.
What are the thread sizes for the connection ports?
The unit features Port 1 (M22x1,5), Port 2 (M16x1,5 x2), and Port 4 (M16x1,50) for standard heavy-duty assembly.
Is this part suitable for heavy-duty trucks?
Yes, it is specifically designed for heavy commercial vehicle brake systems and is compatible with WABCO and VOLVO systems.
Can this be used as a replacement for WABCO systems?
Yes, it serves as an OE-equivalent for WABCO system part number 475 711 145 0.
