303.06.0081 MERCEDES BENZ Complete, ALB Load Sensing Valve
303.06.0081
Summary
●Empty Pressure Port 41/42: 0,6 BAR ●Empty Pressure Port 2: 1,5 BAR ●Full Pressure Port 2: 6,5 BAR ●Full Pressure Port 41/42: 3,5 BAR ●Port 1: M16x1,5 ●Port 2: M16x1,5(x2) ●Port 4: M16x1,50
| EAN Code | 8683457050983 |
|---|
Ready to Order
Compatible OEM Codes
- WABCO 475 711 014 0
- MERCEDES BENZ A0014317212
Description
The braking performance of a heavy commercial vehicle depends heavily on precise pneumatic regulation. This high-strength component functions as a critical control element within the pneumatic brake system to ensure stable pressure distribution based on load variations.
The 303.06.0081 is the OE equivalent of the MERCEDES BENZ A0014317212 and WABCO 4757110140 used in heavy-duty vehicle applications. This component is designed for compatibility with MERCEDES BENZ systems and WABCO hardware. It features specific port configurations including Port 1 (M16x1,5), Port 2 (M16x1,5 x2), and Port 4 (M16x1,50) to meet strict technical requirements.
Technicians should verify the pressure thresholds during installation to ensure optimal system response. The empty pressure port 41/42 is set at 0,6 BAR, while the full pressure port 2 reaches up to 6,5 BAR. Regular inspection of the port connections is recommended to maintain reliable braking performance in commercial fleets.
The 303.06.0081 is the OE equivalent of the MERCEDES BENZ A0014317212 and WABCO 4757110140 used in heavy-duty vehicle applications. This component is designed for compatibility with MERCEDES BENZ systems and WABCO hardware. It features specific port configurations including Port 1 (M16x1,5), Port 2 (M16x1,5 x2), and Port 4 (M16x1,50) to meet strict technical requirements.
Technicians should verify the pressure thresholds during installation to ensure optimal system response. The empty pressure port 41/42 is set at 0,6 BAR, while the full pressure port 2 reaches up to 6,5 BAR. Regular inspection of the port connections is recommended to maintain reliable braking performance in commercial fleets.
Technical Specifications
| Empty Pressure Port 41/42 | 0,6 BAR |
|---|---|
| Empty Pressure Port 2 | 1,5 BAR |
| Full Pressure Port 2 | 6,5 BAR |
| Full Pressure Port 41/42 | 3,5 BAR |
| Port 1 | M16x1,5 |
| Port 2 | M16x1,5(x2) |
| Port 4 | M16x1,50 |
Other OEMs
MERCEDES BENZ
- 001 431 72 12
- A0014317212
WABCO
- 4757110140
- 475 711 014 0
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| MERCEDES BENZ | |||
| WABCO |
FAQ
What are the compatible OEM reference numbers for this part?
This product is compatible with the following OEM numbers: A0014317212, 4757110140.
Which vehicle systems is this component compatible with?
This component is designed for use with MERCEDES BENZ vehicles and WABCO pneumatic systems.
What are the technical pressure specifications for this valve?
The valve features an Empty Pressure Port 41/42 of 0,6 BAR and a Full Pressure Port 2 of 6,5 BAR.
What is the function of the ALB Load Sensing Valve?
The ALB Load Sensing Valve regulates braking force by adjusting pneumatic pressure based on the load applied to the vehicle's axle.
What thread sizes are used for the ports?
The unit utilizes M16x1,5 threads for Port 1, Port 2 (dual), and Port 4.
