303.06.0063 Complete, ALB Load Sensing Valve
303.06.0063
Summary
●Empty Pressure Port 41/42: 0,2 BAR ●Empty Pressure Port 2: 2 BAR ●Full Pressure Port 2: 8 BAR ●Full Pressure Port 41/42: 5,5 BAR ●Port 1: M22x1,5 Voss ●Port 2: M22x1,5 Voss(x2) ●Port 4: M16x1,5 Voss
| EAN Code | 8683457050808 |
|---|
Ready to Order
Compatible OEM Codes
- RENAULT TRUCKS 5019097499 5010097499
- WABCO 475 711 042 0
- IVECO 952074870
- DAF 1518966
Description
This high-strength component is a vital part of the pneumatic braking system, designed to regulate air pressure based on vehicle load. It ensures optimal braking performance and safety in heavy commercial vehicle applications by precisely managing the pressure distribution across the system.
The 303.06.0063 is the OE equivalent of the DAF 1518966, IVECO 952074870, RENAULT TRUCKS 5010097499, RENAULT TRUCKS 5019097499, and WABCO 4757110420 parts. This Complete, ALB Load Sensing Valve is engineered to meet strict technical requirements for reliability in demanding environments.
Technical specifications for this unit include an Empty Pressure Port 41/42 of 0,2 BAR and a Full Pressure Port 41/42 of 5,5 BAR. The connection ports feature M22x1,5 Voss and M16x1,5 Voss threading to ensure a secure and airtight fit during installation within the brake system.
Workshop technicians should verify all port connections and pressure settings during routine maintenance to ensure the braking system maintains peak efficiency. Always consult the official compatibility list to ensure correct application for your specific vehicle model.
The 303.06.0063 is the OE equivalent of the DAF 1518966, IVECO 952074870, RENAULT TRUCKS 5010097499, RENAULT TRUCKS 5019097499, and WABCO 4757110420 parts. This Complete, ALB Load Sensing Valve is engineered to meet strict technical requirements for reliability in demanding environments.
Technical specifications for this unit include an Empty Pressure Port 41/42 of 0,2 BAR and a Full Pressure Port 41/42 of 5,5 BAR. The connection ports feature M22x1,5 Voss and M16x1,5 Voss threading to ensure a secure and airtight fit during installation within the brake system.
Workshop technicians should verify all port connections and pressure settings during routine maintenance to ensure the braking system maintains peak efficiency. Always consult the official compatibility list to ensure correct application for your specific vehicle model.
Technical Specifications
| Empty Pressure Port 41/42 | 0,2 BAR |
|---|---|
| Empty Pressure Port 2 | 2 BAR |
| Full Pressure Port 2 | 8 BAR |
| Full Pressure Port 41/42 | 5,5 BAR |
| Port 1 | M22x1,5 Voss |
| Port 2 | M22x1,5 Voss(x2) |
| Port 4 | M16x1,5 Voss |
Other OEMs
DAF
- 1518966
IVECO
- 952074870
RENAULT TRUCKS
- 5019097499
- 5010097499
WABCO
- 4757110420
- 475 711 042 0
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| DAF | |||
| IVECO | |||
| RENAULT TRUCKS | |||
| WABCO |
FAQ
What are the compatible OEM reference numbers for this part?
This product is compatible with the following references: DAF 1518966, IVECO 952074870, RENAULT TRUCKS 5010097499, RENAULT TRUCKS 5019097499, and WABCO 4757110420.
Which vehicle brands can use this load sensing valve?
This component is designed for use in heavy commercial vehicles from manufacturers such as DAF, IVECO, and RENAULT TRUCKS, and is compatible with WABCO systems.
What are the pressure specifications for the ports?
The unit features an Empty Pressure Port 41/42 of 0,2 BAR and a Full Pressure Port 41/42 of 5,5 BAR to ensure proper pneumatic regulation.
What thread types are used for the connections?
The valve utilizes specific thread types including M22x1,5 Voss for Port 1 and Port 2 (double), and M16x1,5 Voss for Port 4.
Is this part suitable for heavy-duty truck applications?
Yes, this is a high-strength component specifically designed for the braking systems of heavy commercial vehicles and trucks.
