303.06.0060 Complete, ALB Load Sensing Valve — MAN
303.06.0060
The 303.06.0060 is a high-strength component designed for the brake system. It features specific pressure port configurations: Empty Pressure Port 41/42 at 0,8 BAR, Empty Pressure Port 2 at 1,9 BAR, and Full Pressure Port 2 at 6,9 BAR (Full Pressure Port 41/42 at 7 BAR). Port dimensions include M16x1,5 for Port 1 and Port 4, and M16x1,5 (x2) for Port 2.
| EAN Code | 8683457050778 |
|---|
Description
The technical function of this component is to regulate braking pressure based on the vehicle load, ensuring optimal safety and stability in the braking system. Designed as a heavy-duty grade component, it plays a critical role in the pneumatic control of braking forces during heavy commercial vehicle operations.
This product is the OE-equivalent of the MAN 99.10036-0484 and WABCO 475 711 052 0 used in MAN and STEYR heavy commercial vehicles. It is engineered to meet strict industrial standards for reliability and precision in load-sensing applications.
Workshop technicians should ensure all port connections are secure and check for any pneumatic leaks during installation to maintain optimal system performance. The M16x1,5 threading specifications are crucial for a correct fit within the braking architecture of the compatible vehicle systems.
Regular maintenance of the brake system components is essential for long-term durability and safety. Monitoring the pressure thresholds at the designated ports ensures that the load sensing valve continues to function within its intended technical parameters.
Technical Specifications
| Empty Pressure Port 41/42 | 0,8 BAR |
|---|---|
| Empty Pressure Port 2 | 1,9 BAR |
| Full Pressure Port 2 | 6,9 BAR |
| Full Pressure Port 41/42 | 7 BAR |
| Port 1 | M16x1,5 |
| Port 2 | M16x1,5(x2) |
| Port 4 | M16x1,50 |
Other OEMs
MAN
- 99.10036-0484
- 99100360484
WABCO
- 475 711 052 0
- 4757110520
- 4757111000
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Engine |
|---|---|---|
| MAN | ||
| STEYR | ||
| WABCO |
