303.06.0041 Complete, ALB Load Sensing Valve
590 Visualized

303.06.0041 MAN Complete, ALB Load Sensing Valve - MAN

303.06.0041

Summary

The 303.06.0041 is a high-performance ALB Load Sensing Valve designed for heavy commercial vehicle brake systems. It features precise pressure port specifications: Empty Pressure Port 41/42 at 0,8 BAR, Empty Pressure Port 2 at 2,1 BAR, Full Pressure Port 2 at 7,5 BAR, and Full Pressure Port 41/42 at 6,5 BAR. Includes ports M16x1,5 for reliable assembly and operation.

EAN Code8683457050587
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Description

The heavy duty ALB Load Sensing Valve is a critical component within the pneumatic braking system of heavy commercial vehicles, ensuring that braking force is adjusted according to the load weight. This product provides stable pneumatic regulation to maintain optimal braking performance and safety under varying load conditions.

303.06.0041 is the OE-equivalent of the MAN 99.10036-0098 and WABCO 475 711 010 0 ALB Load Sensing Valve used in MAN and STEYR heavy commercial vehicles. This component ensures precise pressure distribution across the braking circuit to support the vehicle's structural integrity during operation.

Designed for professional workshop technicians, this unit features specific port dimensions including Port 1 (M16x1,5), Port 2 (M16x1,5 x2), and Port 4 (M16x1,50). Regular maintenance and checking of these pneumatic connections are essential to prevent pressure leaks and ensure the longevity of the brake system components.

Installation of this valve requires adherence to standard pneumatic assembly protocols to ensure the empty pressure and full pressure thresholds—such as the 7,5 BAR full pressure port—are reached correctly within the system architecture.

Technical Specifications

Empty Pressure Port 41/420,8 BAR
Empty Pressure Port 22,1 BAR
Full Pressure Port 27,5 BAR
Full Pressure Port 41/426,5 BAR
Port 1M16x1,5
Port 2M16x1,5 (x2)
Port 4M16x1,50

Other OEMs

MAN

  • 99.10036-0098
  • 99100360098

WABCO

  • 475 711 010 0
  • 4757110100

Related Products

Repair Kits

Vehicles Used

BrandModelEngine
MAN
STEYR
WABCO

FAQ

Which OEM numbers is this part compatible with?
This product is a direct replacement for MAN 99.10036-0098 and WABCO 475 711 010 0.
What are the specific thread sizes for the ports?
The unit features Port 1 (M16x1,5), Port 2 (M16x1,5 x2), and Port 4 (M16x1,5) for precise fitment.
Is this part suitable for heavy commercial vehicles?
Yes, it is designed specifically for heavy commercial vehicle brake systems like those in MAN or STEYR trucks.
What are the pressure specifications for this valve?
The valve operates with an Empty Pressure Port 41/42 at 0,8 BAR and a Full Pressure Port 2 at 7,5 BAR.
Can this be used in WABCO brake systems?
Yes, it is fully compatible with WABCO systems as indicated by the reference code 475 711 010 0.
