303.06.0022 SCANIA Compatible Complete, ALB Load Sensing Valve
303.06.0022
Summary
The Vaden Original 303.06.0022 is a high-strength component designed for brake systems. It features Port 1: M16x1,5, Port 2: M22x1,5 (x2) - M16x1,5 (x4), Port 4: M22x1,5, Port 41: M12x1,5, and Port 42: M12x1,5. This part is fully compatible with SCANIA and WABCO systems.
| EAN Code | 8683457010222 |
|---|
Ready to Order
Compatible OEM Codes
- WABCO 475 715 507 0
- SCANIA 2090059
Description
The precision of the braking system relies heavily on the performance of load-sensing components to ensure safety under varying weights. This Complete, ALB Load Sensing Valve is engineered with high-strength components to maintain consistent pneumatic pressure and reliability in heavy commercial vehicle applications.
This specific part is the OE equivalent of the SCANIA 2090059 and WABCO 4757155070 used in heavy-duty vehicle braking systems. The 303.06.0022 model ensures optimal load distribution through its specialized port configuration including M16x1,5 and M22x1,5 connections. It is designed to meet the rigorous demands of professional workshop technicians and fleet managers.
Maintenance of the ALB load sensing valve involves checking for pressure stability at the designated ports. For instance, the empty pressure at ports 41 and 42 is set at 0,2 BAR, while the full pressure reaches 5,6 BAR. Regular inspection of these connections ensures the vehicle remains compliant with safety standards during operation.
Vaden Original provides these critical components to support the reliability of heavy commercial vehicle fleets. For precise installation and technical guidance regarding port sizes and pressure thresholds, always consult your authorized distributor.
This specific part is the OE equivalent of the SCANIA 2090059 and WABCO 4757155070 used in heavy-duty vehicle braking systems. The 303.06.0022 model ensures optimal load distribution through its specialized port configuration including M16x1,5 and M22x1,5 connections. It is designed to meet the rigorous demands of professional workshop technicians and fleet managers.
Maintenance of the ALB load sensing valve involves checking for pressure stability at the designated ports. For instance, the empty pressure at ports 41 and 42 is set at 0,2 BAR, while the full pressure reaches 5,6 BAR. Regular inspection of these connections ensures the vehicle remains compliant with safety standards during operation.
Vaden Original provides these critical components to support the reliability of heavy commercial vehicle fleets. For precise installation and technical guidance regarding port sizes and pressure thresholds, always consult your authorized distributor.
Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M22x1,5 (x2) - M16x1,5 (x4) |
| Port 4 | M22x1,5 |
| Port 41 | M12x1,5 |
| Port 42 | M12x1,5 |
| Empty Pressure Port 41 | 0,2 BAR |
| Empty Pressure Port 42 | 0,2 BAR |
| Full Pressure Port 41 | 5,6 BAR |
| Full Pressure Port 42 | 5,6 BAR |
| Port 43 | M16x1,5 |
| Port 1-2 | M22x1,5 |
Other OEMs
SCANIA
- 2090059
WABCO
- 4757155070
- 475 715 507 0
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| SCANIA | |||
| WABCO |
FAQ
What are the technical specifications for the ports?
The unit features Port 1 (M16x1,5), Port 2 (M22x1,5 x2 and M16x1,5 x4), Port 4 (M22x1,5), and Port 41/42 (M12x1,5).
Which OEM numbers is this part compatible with?
This product is compatible with SCANIA 2090059 and WABCO 475715507 much as it serves as an OE equivalent.
What are the pressure ratings for this valve?
The empty pressure for ports 41 and 42 is 0,2 BAR, while the full pressure for these ports reaches 5,6 BAR.
Is this part suitable for heavy commercial vehicles?
Yes, this component is designed specifically for heavy commercial vehicle brake systems to ensure reliable load sensing.
How can I verify compatibility with my system?
You can verify compatibility by checking the port sizes (M16x1,5/M22x1,5) against your current system or by cross-referencing the OEM codes provided.
