303.06.0020 Complete, ALB Load Sensing Valve
529 Visualized

303.06.0020 DAF Complete, ALB Load Sensing Valve

303.06.0020

Summary

●Port 1: M16x1,5 ●Port 2: M22x1,5 (x2) - M16x1,5 (x4) ●Port 4: M22x1,5 ●Port 41: M12x1,5 ●Port 42: M12x1,5 ●Empty Pressure Port 41: 0,4 BAR ●Empty Pressure Port 42: 0,4 BAR ●Full Pressure Port 41: 4,4 BAR ●Full Pressure Port 42: 4,4 BAR ●Port 44: M16x1,5 ●Port 1-2: M22x1,5

EAN Code8683457010208
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Compatible OEM Codes

  • WABCO 475 715 505 0
  • DAF 1518979

Description

The technical function of this ALB Load Sensing Valve is to regulate braking force based on the vehicle's load, ensuring optimal pneumatic stability in the brake system. Designed with heavy-duty grade materials, this component provides essential pressure regulation for heavy commercial vehicle safety and reliability.

303.06.0020 is the OE-equivalent of the DAF 1518979 and WABCO 475 715 505 0 components used in DAF heavy commercial vehicle systems. This part ensures precise compatibility with WABCO systems and DAF braking architectures by maintaining exact pressure thresholds across its multiple specialized ports.

Workshop technicians should note the specific port configurations for assembly: Port 1 utilizes M16x1,5 while Port 2 features a complex arrangement of M22x1,5 and M16x1,5 threads. Maintenance and installation require strict adherence to these thread sizes to ensure a leak-free connection within the pneumatic braking circuit.

Detailed pressure monitoring is facilitated by the specific empty and full pressure ratings. The component maintains a consistent performance profile with an empty pressure of 0,4 BAR at ports 41 and 42, reaching a full pressure of 4,4 BAR to guarantee system integrity during high-load operations.

Technical Specifications

Port 1M16x1,5
Port 2M22x1,5 (x2) - M16x1,5 (x4)
Port 4M22x1,5
Port 41M12x1,5
Port 42M12x1,5
Empty Pressure Port 410,4 BAR
Empty Pressure Port 420,4 BAR
Full Pressure Port 414,4 BAR
Full Pressure Port 424,4 BAR
Port 43M16x1,5
Port 1-2M22x1,5

Other OEMs

DAF

  • 1518979

WABCO

  • 4757155050
  • 475 715 505 0

Vehicles Used

BrandModelEngine
DAF
WABCO

FAQ

What are the compatible OEM numbers for this ALB Load Sensing Valve?
This product is fully compatible with OEM codes DAF 1518979 and WABCO 475 715 505 0.
What are the specific thread sizes for the ports?
The unit features Port 1 (M16x1,5), Port 2 (M22x1,5 and M16x1,5), Port 4 (M22x1,5), and Port 41/42 (M12x1,5).
Is this component suitable for heavy commercial vehicles?
Yes, it is designed specifically for heavy commercial vehicle brake systems requiring precise load sensing.
What are the pressure ratings for the empty and full ports?
The empty pressure for ports 41/42 is 0,4 BAR, while the full pressure reaches 4,4 BAR.
Can this part be used in WABCO systems?
Yes, it is engineered to be compatible with WABCO systems and DAF vehicle models.
