303.06.0019 WABCO Complete, ALB Load Sensing Valve
303.06.0019
Summary
The Vaden Original 303.06.0019 is a high-strength WABCO compatible ALB Load Sensing Valve. It features specialized port configurations including Port 1: M16x1,5; Port 2: M22x1,5 (x2) and M16x1,5 (x4); Port 4: M22x1,5; and Port 41/42: M12x1,5 with pressure settings of 0,5 BAR empty and 4 BAR full.
| EAN Code | 8683457010192 |
|---|
Ready to Order
Compatible OEM Codes
- WABCO 475 715 502 0
Description
This high-strength component serves as a critical element within the brake system, ensuring precise pneumatic control and load-dependent regulation. Designed for heavy-duty performance, it provides reliable pressure modulation to maintain vehicle stability under varying load conditions.
The 303.06.0019 is the OE equivalent of the WABCO 4757155020 component used in professional heavy commercial vehicle systems. This unit is engineered for seamless integration with WABCO hardware and meets rigorous technical standards for durability and precision.
Technical specifications for technicians include Port 1: M16x1,5; Port 2: M22x1,5 (x2) and M16x1,5 (x4); Port 4: M22x1,5; and Port 41/42: M12x1,5. The empty pressure threshold is set at 0,5 BAR for ports 41 and 42, while the full pressure threshold is established at 4 BAR for these ports, ensuring accurate load sensing functionality.
Maintenance professionals should verify all port connections and pressure settings during installation to ensure optimal system response. Proper seating of the M-thread connections is essential for maintaining the integrity of the pneumatic circuit in heavy commercial vehicles.
The 303.06.0019 is the OE equivalent of the WABCO 4757155020 component used in professional heavy commercial vehicle systems. This unit is engineered for seamless integration with WABCO hardware and meets rigorous technical standards for durability and precision.
Technical specifications for technicians include Port 1: M16x1,5; Port 2: M22x1,5 (x2) and M16x1,5 (x4); Port 4: M22x1,5; and Port 41/42: M12x1,5. The empty pressure threshold is set at 0,5 BAR for ports 41 and 42, while the full pressure threshold is established at 4 BAR for these ports, ensuring accurate load sensing functionality.
Maintenance professionals should verify all port connections and pressure settings during installation to ensure optimal system response. Proper seating of the M-thread connections is essential for maintaining the integrity of the pneumatic circuit in heavy commercial vehicles.
Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M22x1,5 (x2) - M16x1,5 (x4) |
| Port 4 | M22x1,5 |
| Port 41 | M12x1,5 |
| Port 42 | M12x1,5 |
| Empty Pressure Port 41 | 0,5 BAR |
| Empty Pressure Port 42 | 0,5 BAR |
| Full Pressure Port 41 | 4 BAR |
| Full Pressure Port 42 | 4 BAR |
| Port 43 | M16x1,5 |
| Port 1-2 | M22x1,5 |
Other OEMs
WABCO
- 4757155020
- 475 715 502 0
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| WABCO |
FAQ
What is the function of the ALB Load Sensing Valve?
The ALB Load Sensing Valve regulates braking force by sensing the load on the vehicle's suspension to adjust pneumatic pressure accordingly.
Which OEM reference does this part match?
This product is a direct OE equivalent for the WABCO 4757155020 system component.
What are the pressure specifications for ports 41 and 42?
The empty pressure threshold is 0,5 BAR and the full pressure threshold is 4 BAR for ports 41 and 42.
Is this part compatible with WABCO systems?
Yes, this component is specifically designed to be compatible with WABCO hardware and technical standards.
What thread sizes are used in this assembly?
The assembly utilizes various thread sizes including M16x1,5, M22x1,5, and M12x1,5 to ensure precise fitment.
