303.06.0017 WABCO Complete, ALB Load Sensing Valve
303.06.0017
Summary
●Port 1: M22x1,5 ●Port 2: M16x1,5 (x2) ●Port 4: M22x1,5 ●Port 41: M12x1,5 ●Port 42: M12x1,5 ●Empty Pressure Port 41: 3 BAR ●Empty Pressure Port 42: 3 BAR ●Full Pressure Port 41: 7 BAR ●Full Pressure Port 42: 7 BAR ●Empty Pressure Port 2: 5,5 BAR ●Full Pressure Port 2: 8 BAR
| EAN Code | 8683457010161 |
|---|
Ready to Order
Compatible OEM Codes
- WABCO 475 714 512 0
Description
The braking system relies on precise pressure regulation to ensure the safety and stability of heavy commercial vehicles. This high-strength component is designed to maintain optimal pneumatic performance under varying load conditions.
The 303.06.0017 is the OE equivalent of the WABCO 475714512 is used in WABCO systems. This product features specialized port configurations including M22x1,5 for Port 1 and Port 4, and M16x1,5 for Port 2 (x2), ensuring a precise fit for professional workshop applications.
Technicians should verify the specific port dimensions and pressure requirements during installation. This unit includes dual pressure ports (Port 41 and Port 42) with an empty pressure rating of 3 BAR and a full pressure rating of 7 BAR to ensure reliable operation within the brake system architecture.
Regular inspection of the pneumatic connections and port integrity is recommended to maintain consistent braking performance. For detailed technical specifications or to confirm compatibility with specific systems, consult your authorized distributor.
The 303.06.0017 is the OE equivalent of the WABCO 475714512 is used in WABCO systems. This product features specialized port configurations including M22x1,5 for Port 1 and Port 4, and M16x1,5 for Port 2 (x2), ensuring a precise fit for professional workshop applications.
Technicians should verify the specific port dimensions and pressure requirements during installation. This unit includes dual pressure ports (Port 41 and Port 42) with an empty pressure rating of 3 BAR and a full pressure rating of 7 BAR to ensure reliable operation within the brake system architecture.
Regular inspection of the pneumatic connections and port integrity is recommended to maintain consistent braking performance. For detailed technical specifications or to confirm compatibility with specific systems, consult your authorized distributor.
Technical Specifications
| Port 1 | M22x1,5 |
|---|---|
| Port 2 | M16x1,5 (x2) |
| Port 4 | M22x1,5 |
| Port 41 | M12x1,5 |
| Port 42 | M12x1,5 |
| Empty Pressure Port 41 | 3 BAR |
| Empty Pressure Port 42 | 3 BAR |
| Full Pressure Port 41 | 7 BAR |
| Full Pressure Port 42 | 7 BAR |
| Empty Pressure Port 2 | 5,5 BAR |
| Full Pressure Port 2 | 8 BAR |
| Port 43 | M16x1,5 |
Other OEMs
WABCO
- 4757145120
- 475 714 512 0
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| WABCO |
FAQ
What is the primary function of this component?
This ALB Load Sensing Valve regulates brake system pressure based on vehicle load to ensure stable braking performance.
Which OEM numbers is this part compatible with?
This product is compatible with WABCO 475714512.
What are the thread specifications for the ports?
The unit features Port 1 (M22x1,5), Port 2 (M16x1,5 x2), Port 4 (M22x1,5), and Port 41/42 (M12x1,5).
Is this part suitable for heavy commercial vehicles?
Yes, this component is specifically engineered for heavy commercial vehicle brake systems requiring precise pneumatic regulation.
How can I ensure correct installation?
Technicians should verify all port sizes and pressure thresholds (Empty: 3 BAR / Full: 7 BAR) against the vehicle's technical requirements before assembly.
