303.06.0015 Complete, ALB Load Sensing Valve
1314 Visualized

303.06.0015 Complete, ALB Load Sensing Valve

303.06.0015

Summary

●Port 1: M22x1,5 ●Port 2: M16x1,5 (x2) ●Port 4: M22x1,5 ●Port 41: M12x1,5 ●Port 42: M12x1,5 ●Empty Pressure Port 41: 0,4 BAR ●Empty Pressure Port 42: 0,4 BAR ●Full Pressure Port 41: 3,6 BAR ●Full Pressure Port 42: 3,6 BAR ●Empty Pressure Port 2: 2,4 BAR ●Full Pressure Port 2: 6,5 BAR ●Port 44: M16x1,5

EAN Code8683457010147
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Compatible OEM Codes

  • WABCO 475 714 510 0
  • SCANIA 1935107
  • DAF 1506230

Description

The technical specifications of this component ensure precise pneumatic regulation within the heavy commercial vehicle brake system. This complete assembly is engineered to handle varying pressure loads effectively, maintaining optimal braking performance through high-strength components and reliable pressure modulation.

303.06.0015 is the OE equivalent of the DAF 1506230, SCANIA 1935107, and WABCO 475 714 510 0 load sensing valve used in DAF and SCANIA heavy vehicles. This part is designed to meet strict industrial standards for heavy-duty commercial vehicle applications.

Workshop technicians can rely on the precise port configurations for seamless integration into existing pneumatic brake circuits. The unit features specific port sizes including M22x1,5 and M16x1,5 to ensure a secure fit and prevent air leakage during operation. Regular inspection of the pressure ports and connections is recommended during standard maintenance intervals to ensure system integrity.

This valve is essential for maintaining stable braking force under varying load conditions. It provides critical feedback to the braking system, ensuring that the pneumatic pressure is adjusted according to the weight of the vehicle or trailer.

Technical Specifications

Port 1M22x1,5
Port 2M16x1,5 (x2)
Port 4M22x1,5
Port 41M12x1,5
Port 42M12x1,5
Empty Pressure Port 410,4 BAR
Empty Pressure Port 420,4 BAR
Full Pressure Port 413,6 BAR
Full Pressure Port 423,6 BAR
Empty Pressure Port 22,4 BAR
Full Pressure Port 26,5 BAR
Port 43M16x1,5

Other OEMs

DAF

  • 1506230

SCANIA

  • 1935107

WABCO

  • 4757145100
  • 475 714 510 0

Vehicles Used

BrandModelEngine
DAF
KEMPF
SCANIA
SCHMITZ CARGOBULL
WABCO

FAQ

Which vehicles are compatible with this load sensing valve?
This part is compatible with DAF (1506230), SCANIA (1935107), and WABCO (475 714 510 0) systems.
What are the technical port specifications for this unit?
The unit features Port 1 (M22x1,5), Port 2 (M16x1,5 x2), Port 4 (M22x1,5), and Port 44 (M16x1,5).
Can this part be used as an OE replacement?
Yes, it serves as an OE equivalent for DAF code 1506230 and SCANIA code 1935107.
Is this component suitable for heavy commercial vehicles?
Yes, it is specifically designed for heavy commercial vehicle brake systems including trucks and buses.
What are the pressure settings for the empty/full ports?
Empty pressure for ports 41/42 is 0,4 BAR; Full pressure for ports 41/42 is 3,6 BAR.
