303.06.0014 Complete, ALB Load Sensing Valve
1432 Visualized

303.06.0014 Complete, ALB Load Sensing Valve

303.06.0014

Summary

●Port 1: M22x1,5 ●Port 2: M16x1,5 (x2) ●Port 4: M22x1,5 ●Port 41: M12x1,5 ●Port 42: M12x1,5 ●Empty Pressure Port 41/42: 0,7 BAR ●Full Pressure Port 41/42: 4,7 BAR ●Empty Pressure Port 2: 2,6 BAR ●Full Pressure Port 2: 6,5 BAR ●Port 44: M16x1,5

EAN Code8683457010130
Ready to Order
Get Information
Share
WhatsApp Facebook X LinkedIn

Compatible OEM Codes

  • WABCO 475 714 509 0
  • SCANIA 2090020
  • KRONE 58110450
  • KÖGEL 76934
  • DAF 1506229

Description

The heavy-duty Complete, ALB Load Sensing Valve is a precision-engineered component designed to regulate braking force based on vehicle load. This part ensures optimal pneumatic stability and safety within the brake system by accurately managing pressure distribution across various ports. Built with high-strength components, it maintains consistent performance under demanding heavy commercial vehicle operations.

303.06.0014 is the OE-equivalent of the WABCO 475 714 509 0 Complete, ALB Load Sensing Valve used in DAF, SCANIA, KÖGEL, KRONE, and other heavy-duty systems. This component is engineered to meet strict technical specifications for seamless integration with compatible braking hardware and vehicle architectures.

The assembly features specific port configurations including M22x1,5 and M16x1,5 interfaces to ensure a precise fit during installation. Workshop technicians should verify all port measurements and pressure thresholds—such as the 0,7 BAR empty pressure and 4,7 BAR full pressure settings—to ensure perfect synchronization with the existing pneumatic circuit and maintain optimal braking efficiency.

Technical Specifications

Port 1M22x1,5
Port 2M16x1,5 (x2)
Port 4M22x1,5
Port 41M12x1,5
Port 42M12x1,5
Empty Pressure Port 410,7 BAR
Empty Pressure Port 420,7 BAR
Full Pressure Port 414,7 BAR
Full Pressure Port 424,7 BAR
Empty Pressure Port 22,6 BAR
Full Pressure Port 26,5 BAR
Port 43M16x1,5

Other OEMs

DAF

  • 1506229

KÖGEL

  • 76934

KRONE

  • 58110450

SCANIA

  • 2090020

WABCO

  • 4757145090
  • 475 714 509 0

Vehicles Used

BrandModelEngine
DAF
FAYMONVILLE
FELDBINDER
GOLDHOFER
KEMPF
KENWORTH
KÖGEL
KRONE
LANGENDORF
MERITOR
PETERBILT
SCANIA
SCHMITZ CARGOBULL
SCHWARZMULLER
VAN HOOL
WABCO

FAQ

What are the compatible OEM numbers for this part?
This part is compatible with WABCO 475 714 509 0, DAF 1506229, SCANIA 2090020, KÖGEL 76934, and KRONE 5811045. It is designed for high-performance braking systems.
Which vehicle brands can use this ALB Load Sensing Valve?
It is compatible with heavy commercial vehicle brands including DAF, SCANIA, KÖGEL, KRONE, and systems manufactured by WABCO.
What are the technical port specifications for installation?
The unit features Port 1 (M22x1,5), Port 2 (M16x1,5 x2), Port 4 (M22x1,5), Port 41/42 (M12x1,5), and Port 44 (M16x1,5) for precise pneumatic connection.
Does this part meet heavy-duty requirements?
Yes, it is constructed with high-strength components designed specifically for the rigorous demands of the heavy commercial vehicle brake system.
What are the pressure thresholds for this valve?
The valve operates with an empty pressure of 0,7 BAR for ports 41/42 and a full pressure of up to 4,7 BAR for those same ports to ensure regulated braking.
