303.02.0028 4-circuit protection valve
303.02.0028
Summary
●Port 1: M22x1,5 ●Port 21: M16x1,5 ●Port 22: M16x1,5 ●Port 23: M16x1,5 ●Port 24: M16x1,5 ●Operating Pressure: 13 BAR ●Opening Pressure 21: 7,5 BAR ●Opening Pressure 22: 7,5 BAR ●Opening Pressure 23: 8 BAR ●Opening Pressure 24: 8 BAR ●Closing Pressure 21: 6,5 BAR ●Closing Pressure 22: 6,5 BAR ●Closing Pressure 23: 6,5 BAR ●Closing Pressure 24: 6,5 BAR ●Pressure: MAX 20 BAR
| EAN Code | 8699031092874 |
|---|
Ready to Order
Compatible OEM Codes
- KNORR-BREMSE K019909N00 AE 4646
- IVECO 98400429
Description
VADEN ORIGINAL 303.02.0028 is an equivalent part in the 4-circuit protection valve group matching the original KNORR-BREMSE (AE4646, K019909N00), IVECO (98400429) references. Its OE-quality manufacturing process preserves the vehicle's performance and lowers maintenance costs.
Technical Specifications
| Port 1 | M22x1,5 |
|---|---|
| Port 21 | M16x1,5 |
| Port 22 | M16x1,5 |
| Port 23 | M16x1,5 |
| Port 24 | M16x1,5 |
| Operating Pressure | 13 BAR |
| Opening Pressure 21 | 7,5 BAR |
| Opening Pressure 22 | 7,5 BAR |
| Opening Pressure 23 | 8 BAR |
| Opening Pressure 24 | 8 BAR |
| Closing Pressure 21 | 6,5 BAR |
| Closing Pressure 22 | 6,5 BAR |
| Closing Pressure 23 | 6,5 BAR |
| Closing Pressure 24 | 6,5 BAR |
| Pressure | MAX 20 BAR |
Other OEMs
IVECO
- 98400429
KNORR-BREMSE
- AE4646
- K019909N00
- AE 4646
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| IVECO | |||
| KNORR-BREMSE |
