301.07.0062 Pressure Limiting Valve
301.07.0062
Summary
●Port 1: M16x1,5 ●Port 2: M16x1,5 ●Inlet Pressure: 8 BAR ●Adjustment Range: 4,0 …..8,0 BAR ●Outlet Pressure: 5,7 BAR ± 0,2 BAR ●Safety Pressure: 8,2 BAR
| EAN Code | 8683457011670 |
|---|
Ready to Order
Compatible OEM Codes
- WABCO 475 015 510 0
- KING LONG 235500950
Description
VADEN ORIGINAL 301.07.0062 is the OE-quality equivalent of the original WABCO (4750155100), KING LONG (235500950) references in the Pressure Limiting Valve group. It is produced to fit the original dimensions and mounting points exactly and runs trouble-free after installation.
Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M16x1,5 |
| Inlet Pressure | 8 BAR |
| Adjustment Range | 4,0 …..8,0 BAR |
| Outlet Pressure | 5,7 BAR ± 0,2 BAR |
| Safety Pressure | 8,2 BAR |
Other OEMs
KING LONG
- 235500950
WABCO
- 4750155100
- 475 015 510 0
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| KING LONG | |||
| WABCO |
