301.07.0059 Pressure Limiting Valve
301.07.0059
Summary
●Port 1: M16x1,5 ●Port 2: M16x1,5 ●Inlet Pressure: 8,5 BAR ●Adjustment Range: 4,0 …..8,0 BAR ●Outlet Pressure: 6,0 BAR ●Safety Pressure: 8,5 BAR
| EAN Code | 8683457011649 |
|---|
Ready to Order
Compatible OEM Codes
- WABCO 475 015 501 0
Description
The VADEN ORIGINAL product, code 301.07.0059, can be used in place of the Pressure Limiting Valve part in the WABCO (4750155010) references. Its OE-quality manufacturing delivers performance equivalent to the original.
Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M16x1,5 |
| Inlet Pressure | 8,5 BAR |
| Adjustment Range | 4,0 …..8,0 BAR |
| Outlet Pressure | 6,0 BAR |
| Safety Pressure | 8,5 BAR |
Other OEMs
WABCO
- 4750155010
- 475 015 501 0
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| WABCO |
