301.07.0058 Pressure Limiting Valve
301.07.0058
Summary
●Port 1: M16x1,5 ●Port 2: M16x1,5 ●Inlet Pressure: 8,5 BAR ●Adjustment Range: 4,0 …..8,0 BAR ●Outlet Pressure: 6,5 BAR ± 0,2 BAR ●Safety Pressure: 9,0 BAR
| EAN Code | 8683457011632 |
|---|
Ready to Order
Compatible OEM Codes
- SCANIA 1912299 1370608 1012128
- LOHR A05021206 80239437
- WABCO 475 015 500 0
- VOLVO 11190926
- VDL 28220100700
- VAN HOOL 637211400
- OTOKAR 13H0008530AA
- NOOTEBOOM 308062
- IVECO 8010002097MO
- DAF 1506196
Description
The VADEN ORIGINAL Pressure Limiting Valve part, code 301.07.0058, is equivalent to the original SCANIA (1012128, 1370608, 1912299), LOHR (80239437, A05021206), WABCO (4750155000), VOLVO (11190926), VDL (28220100700), VAN HOOL (637211400), OTOKAR (13H0008530AA), NOOTEBOOM (308062), IVECO (8010002097MO), DAF (1506196) numbers. It is produced with OE-quality materials to meet the demands of heavy commercial vehicle systems.
Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M16x1,5 |
| Inlet Pressure | 8,5 BAR |
| Adjustment Range | 4,0 …..8,0 BAR |
| Outlet Pressure | 6,5 BAR ± 0,2 BAR |
| Safety Pressure | 9,0 BAR |
Other OEMs
DAF
- 1506196
IVECO
- 8010002097MO
LOHR
- A05021206
- 80239437
NOOTEBOOM
- 308062
OTOKAR
- 13H0008530AA
SCANIA
- 1912299
- 1370608
- 1012128
VAN HOOL
- 637211400
VDL
- 28220100700
VOLVO
- 11190926
WABCO
- 4750155000
- 475 015 500 0
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| DAF | |||
| IVECO | |||
| LOHR | |||
| NOOTEBOOM | |||
| OTOKAR | |||
| SCANIA | |||
| VAN HOOL | |||
| VDL | |||
| VOLVO | |||
| WABCO |
