301.07.0056 Pressure Limiting Valve
301.07.0056
Summary
●Port 1: M16x1,5 ●Port 2: M16x1,5 ●Inlet Pressure: 12 BAR ●Adjustment Range: 4,0 …..8,0 BAR ●Outlet Pressure: 8,5 BAR - 0,4 BAR ●Safety Pressure: 11,0 BAR
| EAN Code | 8683457011618 |
|---|
Ready to Order
Compatible OEM Codes
- VOLVO 20382312 20382306
- WABCO 475 015 063 0
- SCANIA 1935026
- DAF 1524015
Description
On heavy commercial vehicles, the Pressure Limiting Valve is a critical part for the safe operation of the system. VADEN ORIGINAL 301.07.0056 is manufactured to OE-quality standards as an equivalent for the original VOLVO (20382306, 20382312), WABCO (4750150630), SCANIA (1935026), DAF (1524015) references.
Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M16x1,5 |
| Inlet Pressure | 12 BAR |
| Adjustment Range | 4,0 …..8,0 BAR |
| Outlet Pressure | 8,5 BAR - 0,4 BAR |
| Safety Pressure | 11,0 BAR |
Other OEMs
DAF
- 1524015
SCANIA
- 1935026
VOLVO
- 20382312
- 20382306
WABCO
- 4750150630
- 475 015 063 0
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| DAF | |||
| SCANIA | |||
| VOLVO | |||
| WABCO |
