301.07.0044 Pressure Limiting Valve
301.07.0044
Summary
●Port 1: M16x1,5 ●Port 2: M16x1,5 ●Inlet Pressure: 10 BAR ●Adjustment Range: 4,0 …..8,0 BAR ●Outlet Pressure: 4,0 BAR + 0,2 BAR ●Safety Pressure: 6,3 BAR
| EAN Code | 8683457011496 |
|---|
Ready to Order
Compatible OEM Codes
- MAN 99.11236-0088 88.52101-6009
- WABCO 475 015 015 0
- VOLVO 21410696
- SCANIA 2090286
- RENAULT TRUCKS 5010559251
- MERCEDES BENZ 002 431 54 06
- IVECO 500346852
Description
On heavy commercial vehicles, the Pressure Limiting Valve is a critical part for the safe operation of the system. VADEN ORIGINAL 301.07.0044 is manufactured to OE-quality standards as an equivalent for the original MAN (88521016009, 99112360088), WABCO (4750150150), VOLVO (21410696), SCANIA (2090286), RENAULT TRUCKS (5010559251), MERCEDES BENZ (0024315406), IVECO (500346852) references.
Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M16x1,5 |
| Inlet Pressure | 10 BAR |
| Adjustment Range | 4,0 …..8,0 BAR |
| Outlet Pressure | 4,0 BAR + 0,2 BAR |
| Safety Pressure | 6,3 BAR |
Other OEMs
IVECO
- 500346852
MAN
- 99112360088
- 88521016009
- 99.11236-0088
- 88.52101-6009
MERCEDES BENZ
- A0024315406
- 002 431 54 06
RENAULT TRUCKS
- 5010559251
SCANIA
- 2090286
VOLVO
- 21410696
WABCO
- 4750150150
- 475 015 015 0
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| IVECO | |||
| MAN | |||
| MERCEDES BENZ | |||
| RENAULT TRUCKS | |||
| SCANIA | |||
| VOLVO | |||
| WABCO |
