301.07.0043 Pressure Limiting Valve
301.07.0043
Summary
●Port 1: M16x1,5 ●Port 2: M16x1,5 ●Inlet Pressure: 8 BAR ●Adjustment Range: 4,0 …..8,0 BAR ●Outlet Pressure: 5,7 BAR + 0,2 BAR ●Safety Pressure: 8,0 BAR
| EAN Code | 8683457011489 |
|---|
Ready to Order
Compatible OEM Codes
- WABCO 475 015 010 0
- SCANIA 2090284
- MERCEDES BENZ 002 431 23 06
Description
VADEN ORIGINAL 301.07.0043 is a part in the Pressure Limiting Valve group equivalent to the original WABCO (4750150100), SCANIA (2090284), MERCEDES BENZ (0024312306) numbers. It is designed for safe, OE-quality use on trucks, buses and tractor units.
Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M16x1,5 |
| Inlet Pressure | 8 BAR |
| Adjustment Range | 4,0 …..8,0 BAR |
| Outlet Pressure | 5,7 BAR + 0,2 BAR |
| Safety Pressure | 8,0 BAR |
Other OEMs
MERCEDES BENZ
- A0024312306
- 002 431 23 06
SCANIA
- 2090284
WABCO
- 4750150100
- 475 015 010 0
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| MERCEDES BENZ | |||
| SCANIA | |||
| WABCO |
