301.07.0039 Pressure Limiting Valve
301.07.0039
Summary
●Port 1: M16x1,5 ●Port 2: M16x1,5 ●Inlet Pressure: 8 BAR ●Adjustment Range: 3,5 …..4,5 BAR ●Outlet Pressure: 3,5 BAR + 0,2 BAR ●Safety Pressure: 5,6 BAR
| EAN Code | 8683457011441 |
|---|
Ready to Order
Compatible OEM Codes
- MAN 81.52101-9153 81.52101-6154 81.52101-6153
- MERCEDES BENZ 002 431 12 06 001 431 63 06
- IVECO 5006002630 04457300
- WABCO 475 015 004 0
- VDL 28210202000
- SCANIA 1935023
- NEOPLAN 110243200
- DAF 1517895
Description
Choosing the right equivalent part reduces the risk of breakdown on a heavy commercial vehicle. VADEN ORIGINAL 301.07.0039 is an OE-quality equivalent to the original Pressure Limiting Valve reference MAN (81521016153, 81521016154, 81521019153), MERCEDES BENZ (0014316306, 0024311206), IVECO (04457300, 5006002630), WABCO (4750150040), VDL (28210202000), SCANIA (1935023), NEOPLAN (110243200), DAF (1517895) ; a safe and economical choice.
Technical Specifications
| Port 1 | M16x1,5 |
|---|---|
| Port 2 | M16x1,5 |
| Inlet Pressure | 8 BAR |
| Adjustment Range | 3,5 …..4,5 BAR |
| Outlet Pressure | 3,5 BAR + 0,2 BAR |
| Safety Pressure | 5,6 BAR |
Other OEMs
DAF
- 1517895
IVECO
- 5006002630
- 04457300
MAN
- 81521019153
- 81521016154
- 81521016153
- 81.52101-9153
- 81.52101-6154
- 81.52101-6153
MERCEDES BENZ
- A0024311206
- A0014316306
- A001 431 63 06
- 002 431 12 06
- 001 431 63 06
NEOPLAN
- 110243200
SCANIA
- 1935023
VDL
- 28210202000
WABCO
- 4750150040
- 475 015 004 0
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| DAF | |||
| IVECO | |||
| MAN | |||
| MERCEDES BENZ | |||
| NEOPLAN | |||
| SCANIA | |||
| VDL | |||
| WABCO |
