301.03.0110 Complete, Air Processing Unit
301.03.0110
Summary
●Heater: 24 V ●Port 1: M22x1,5 ●Port 21: M16x1,5 ●Pressure: 10,4 BAR. This high-strength component is a premium replacement for DAF and KNORR-BREMSE systems.
| EAN Code | 8699031081649 |
|---|
Ready to Order
Compatible OEM Codes
- KNORR-BREMSE LA 8645 K116879N52 K116879N50
- DAF 2107984
Description
This advanced air processing component plays a critical role in the pneumatic regulation of the vehicle's brake system. Designed for heavy commercial vehicle applications, it ensures consistent pressure levels and optimal system stability under demanding operating conditions.
The 301.03.0110 is the OE equivalent of the DAF 2107984 and KNORR-BREMSE K116879N50, K116879N52, and LA8645 parts used in heavy-duty systems. It features a 24 V heater and specific port configurations including M22x1,5 and M16x1,5 to ensure precise integration with existing hardware.
Technicians can rely on this unit for maintaining stable air pressure of 10,4 BAR within the braking circuit. It is engineered to meet the rigorous requirements of professional workshop standards for reliability and durability.
When performing routine maintenance or system overhauls, ensure all connections are checked against the technical specifications to maintain optimal pneumatic performance in the vehicle.
The 301.03.0110 is the OE equivalent of the DAF 2107984 and KNORR-BREMSE K116879N50, K116879N52, and LA8645 parts used in heavy-duty systems. It features a 24 V heater and specific port configurations including M22x1,5 and M16x1,5 to ensure precise integration with existing hardware.
Technicians can rely on this unit for maintaining stable air pressure of 10,4 BAR within the braking circuit. It is engineered to meet the rigorous requirements of professional workshop standards for reliability and durability.
When performing routine maintenance or system overhauls, ensure all connections are checked against the technical specifications to maintain optimal pneumatic performance in the vehicle.
Technical Specifications
| Heater | 24 V |
|---|---|
| Port 1 | M22x1,5 |
| Port 21 | M16x1,5 |
| Pressure | 10,4 BAR |
Other OEMs
DAF
- 2107984
KNORR-BREMSE
- LA8645
- LA 8645
- K116879N52
- K116879N50
Related Products
Repair Kits
Products Used in
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| DAF | |||
| KNORR-BREMSE | |||
| KNORR-BREMSE | |||
| KNORR-BREMSE | |||
| KNORR-BREMSE | |||
| KNORR-BREMSE | |||
| KNORR-BREMSE | |||
| KNORR-BREMSE | |||
| KNORR-BREMSE |
FAQ
What are the compatible OEM reference numbers for this unit?
The compatible OEM codes are DAF 2107984, KNORR-BREMSE K116879N50, K116879N52, and LA8645.
Which vehicle manufacturers is this part compatible with?
This unit is designed for compatibility with DAF and KNORR-BREMSE systems in heavy commercial vehicles.
What are the technical specifications of the ports?
The unit features a Port 1 size of M22x1,5 and a Port 21 size of M16x1,5.
Does this component require a specific voltage?
Yes, this air processing unit is equipped with a 24 V heater for stable operation.
Can this part be used in passenger cars?
No, this component is strictly engineered for heavy commercial vehicle braking systems such as trucks and buses.
