301.01.0041 WABCO Compatible Unloader Valves
301.01.0041
●Port 1: M22x1,5 ●Port 4: - ●Port 21: M22x1,5 ●Cut-Out Pressure: 9,5 BAR/0,2 BAR ●Inflation Valve: ✓
| EAN Code | 8683457011267 |
|---|
Description
The heavy-duty unloader valve is a critical component within the pneumatic brake system, designed to manage air pressure regulation with high precision. This part ensures stable pressure-switching functions, which are essential for the reliable operation of heavy commercial vehicle braking systems.
301.01.0041 is the OE-equivalent of the WABCO 975 300 140 0 unloader valve used in IVECO and RENAULT TRUCKS vehicles. It is also fully compatible with the original specifications of the 02517678 and 5000809518 parts to ensure seamless integration into existing air brake architectures.
Workshop technicians can rely on this component for its standardized port dimensions, featuring M22x1,5 threading on both Port 1 and Port 21. The cut-out pressure of 9,5 BAR / 0,2 BAR ensures precise pneumatic control during vehicle operation and system maintenance.
Technical Specifications
| Port 1 | M22x1,5 |
|---|---|
| Port 4 | - |
| Port 21 | M22x1,5 |
| Cut-Out Pressure | 9,5 BAR / 0,2 BAR |
| Inflation Valve | OK |
Other OEMs
IVECO
- 02517678
RENAULT TRUCKS
- 5000809518
WABCO
- 975 300 140 0
- 9753001400
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Engine |
|---|---|---|
| IVECO | ||
| RENAULT TRUCKS | ||
| WABCO |
