301.01.0014 Unloader Valves — WABCO Compatible
301.01.0014
●Port 1: M22x1,5 ●Port 21: M22x1,5 ●Port 23: M12x1,5 ●Plugged: OK ●Cut-Out Pressure: 12,5 BAR / 0,2 BAR ●Recycle Valve: OK. Designed for high-strength performance in brake systems.
| EAN Code | 8683457010994 |
|---|
Description
This high-strength component serves as a critical element within the pneumatic brake system, ensuring precise pressure regulation and operational stability. Engineered with heavy-duty grade materials, the unloader valve maintains consistent performance under demanding heavy commercial vehicle conditions.
301.01.0014 is the OE-equivalent of the WABCO 975 303 141 0 unloader valve used in DAF, IVECO, VOLVO, and MACK systems. It also provides seamless compatibility with various models from IRISBUS, KENWORTH, PETERBILT, and MERITOR to ensure reliable air management across diverse fleets.
The installation process is designed for workshop technicians to ensure a precise fit with existing port configurations (M22x1,5 and M12x1,5). Proper maintenance of the unloader valve is essential for maintaining optimal cut-out pressure and preventing system leaks in heavy-duty transport applications.
Vaden Original provides professional-grade components that meet the rigorous technical requirements of modern commercial vehicle braking systems.
Technical Specifications
| Port 1 | M22x1,5 |
|---|---|
| Port 4 | - |
| Port 21 | M22x1,5 |
| Port 22 | - |
| Port 23 | M12x1,5 |
| Plugged | OK |
| Cut-Out Pressure | 12,5 BAR / 0,2 BAR |
| Inflation Valve | - |
| Recycle Valve | OK |
Other OEMs
DAF
- 1519346
IRISBUS
- 98412323
IVECO
- 98412322
- 99433866
KENWORTH
- S9753031410
MACK
- 6300-9753031410
MERITOR
- S 9753031410
PETERBILT
- S 9753031410
VOLVO
- WAB9753031410
WABCO
- 975 303 141 0
- 9753031410
