2900 010 005 Single Cylinder, Air Compressor
2900 010 005
Summary
●Cylinder Bore: Ø85.00 ●Stroke: 56 mm ●Swept Volume: 318cm³ ●Air Inlet Port: 3/4”-14 NPT ●Air Outlet Port: 3/4”-14 NPT ●Number of Cylinders: 1 ●Through Drive: ✓ ●Air Unloader Port: M10x1 ●Water (W) or Air (A) Cooled: W ●Water Inlet Port: 1/2”-14 NPT ●Water Outlet Port: 1/2”-14 NPT ●With ESS Feature: ✓
| EAN Code | 8699031071022 |
|---|
Ready to Order
Compatible OEM Codes
- WABCO 911 155 050 0
- VOLKSWAGEN TRUCK 2TO 100 759A
Description
VADEN ORIGINAL 2900 010 005 is the OE-quality equivalent of the original WABCO (9111550500), VOLKSWAGEN TRUCK (2TO100759A) references in the Single Cylinder, Air Compressor group. It is produced to fit the original dimensions and mounting points exactly and runs trouble-free after installation.
Technical Specifications
| Cylinder Bore | Ø85.00 |
|---|---|
| Stroke | 56 mm |
| Swept Volume | 318cm³ |
| Air Inlet Port | 3/4”-14 NPT |
| Air Outlet Port | 3/4”-14 NPT |
| Number of Cylinders | 1 |
| Through Drive | OK |
| Air Unloader Port | M10x1 |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | 1/2”-14 NPT |
| Water Outlet Port | 1/2”-14 NPT |
| With ESS Feature | OK |
Other OEMs
VOLKSWAGEN TRUCK
- 2TO100759A
- 2TO.100.759A
- 2TO 100 759A
WABCO
- 9111550500
- 911.155.050.0
- 911 155 050 0
