2500 290 001 Single Cylinder, Air Compressor
2500 290 001
Summary
●Cylinder Bore: Ø78.00 ●Stroke: 47mm ●Swept Volume: 225cm³ ●Air Inlet Port: M26x1,5 ●Air Outlet Port: M22x1,5 ●Number of Cylinders: 1 ●Through Drive: ✓ ●Water (W) or Air (A) Cooled: W ●Water Inlet Port: M16x1,5 ●Water Outlet Port: M16x1,5
| EAN Code | 8699031078267 |
|---|
Ready to Order
Compatible OEM Codes
- KNORR-BREMSE LK3880
- CUMMINS 4932265
Description
Meet your Single Cylinder, Air Compressor needs on trucks, buses and tractor units with VADEN ORIGINAL 2500 290 001. Compatible with the KNORR-BREMSE (LK3880), CUMMINS (4932265) references, this equivalent part is manufactured to OE-quality standards.
Technical Specifications
| Cylinder Bore | Ø78.00 |
|---|---|
| Stroke | 47mm |
| Swept Volume | 225cm³ |
| Air Inlet Port | M26x1,5 |
| Air Outlet Port | M22x1,5 |
| Number of Cylinders | 1 |
| Through Drive | OK |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M16x1,5 |
| Water Outlet Port | M16x1,5 |
Other OEMs
CUMMINS
- 4932265
KNORR-BREMSE
- LK3880
