2500 260 001 Single Cylinder, Air Compressor
2500 260 001
Summary
●Cylinder Bore: Ø80.00 ●Stroke: 45 mm ●Swept Volume: 225cm³ ●Air Inlet Port: M26x1,5 ●Air Outlet Port: M22x1,5 ●Number of Cylinders: 1 ●Through Drive: ✓ ●Air Unloader Port: M10x1 ●Water (W) or Air (A) Cooled: W ●Water Inlet Port: M16x1,5 ●Water Outlet Port: M16x1,5 ●With ESS Feature: ✓ ●Water Cooled Valve Plate: ✓
| EAN Code | 8699031069630 |
|---|
Ready to Order
Compatible OEM Codes
- KNORR-BREMSE K006282
- CUMMINS 3975798
Description
VADEN ORIGINAL 2500 260 001 in the Single Cylinder, Air Compressor group is an OE-quality equivalent to the original KNORR-BREMSE (K006282), CUMMINS (3975798) references. It is produced for safe, long-lasting use on trucks and buses.
Technical Specifications
| Cylinder Bore | Ø80.00 |
|---|---|
| Stroke | 45 mm |
| Swept Volume | 225cm³ |
| Air Inlet Port | M26x1,5 |
| Air Outlet Port | M22x1,5 |
| Number of Cylinders | 1 |
| Through Drive | OK |
| Air Unloader Port | M10x1 |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | M16x1,5 |
| Water Outlet Port | M16x1,5 |
| With ESS Feature | OK |
| Water Cooled Valve Plate | OK |
Other OEMs
CUMMINS
- 3975798
KNORR-BREMSE
- K006282
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| CUMMINS | |||
| KNORR-BREMSE |
