2200 020 002 BENDIX Compatible Single Cylinder, Air Compressor
2200 020 002
Summary
●Cylinder Bore: Ø92.00 ●Stroke: 54 mm ●Swept Volume: 360cm³ ●Air Inlet Port: 7/8’’-14 UNF ●Air Outlet Port: 3/16’’-12 UN ●Number of Cylinders: 1 ●Through Drive: OK ●Air Unloader Port: 1/8”-27 NPT ●Water (W) or Air (A) Cooled: W ●Water Inlet Port: 3/4’’-16 UNF ●Water Outlet Port: 3/4’’-16 UNF ●Weight: 22,6 KG
| EAN Code | 8699031068695 |
|---|
Ready to Order
Compatible OEM Codes
- CATERPILLAR 255-4160 223-3637 223-3636 191-6521 10R-1437 0R-1624 0R-1623
- BENDIX 5014482 5014428 5012532 5011441 5011427 5010806 5010803
Description
This high-strength single cylinder air compressor is engineered to provide consistent pneumatic pressure for heavy-duty industrial applications. Designed with a robust single-cylinder structure, it ensures reliable operation within the air brake system of specialized machinery and heavy vehicles.
The 2200 020 002 is the OE equivalent of the BENDIX 5010803, 5010806, 5011427, 5011441, 5012532, 5014428, 5014482, CATERPILLAR 0R1623, 0R1624, 10R1437, 1916521, 2233636, 2233637, and 2554160 components. It is fully compatible with BENDIX and CATERPILLAR systems, ensuring seamless integration into existing pneumatic architectures.
Technical precision is maintained through a water-cooled design featuring a Ø92.00 mm cylinder bore and a 54 mm stroke. The unit features a specialized water-cooled valve plate and an air unloader port of 1/8”-27 NPT to manage thermal loads effectively during high-duty cycles. The physical weight of the component is approximately 22.6 KG.
For maintenance professionals and fleet managers, this component offers a reliable replacement option that meets strict industrial standards. Ensure proper installation by verifying the port sizes and cooling connections against the vehicle service manual. Consult your authorized distributor for further technical assistance.
The 2200 020 002 is the OE equivalent of the BENDIX 5010803, 5010806, 5011427, 5011441, 5012532, 5014428, 5014482, CATERPILLAR 0R1623, 0R1624, 10R1437, 1916521, 2233636, 2233637, and 2554160 components. It is fully compatible with BENDIX and CATERPILLAR systems, ensuring seamless integration into existing pneumatic architectures.
Technical precision is maintained through a water-cooled design featuring a Ø92.00 mm cylinder bore and a 54 mm stroke. The unit features a specialized water-cooled valve plate and an air unloader port of 1/8”-27 NPT to manage thermal loads effectively during high-duty cycles. The physical weight of the component is approximately 22.6 KG.
For maintenance professionals and fleet managers, this component offers a reliable replacement option that meets strict industrial standards. Ensure proper installation by verifying the port sizes and cooling connections against the vehicle service manual. Consult your authorized distributor for further technical assistance.
Technical Specifications
| Cylinder Bore | Ø92.00 |
|---|---|
| Stroke | 54 mm |
| Swept Volume | 360cm³ |
| Air Inlet Port | 7/8’’-14 UNF |
| Air Outlet Port | 3/16’’-12 UN |
| Number of Cylinders | 1 |
| Through Drive | OK |
| Air Unloader Port | 1/8”-27 NPT |
| Water (W) or Air (A) Cooled | W |
| Water Inlet Port | 3/4’’-16 UNF |
| Water Outlet Port | 3/4’’-16 UNF |
| With ESS Feature | OK |
| Water Cooled Valve Plate | OK |
| Weight | 22,6 KG |
Other OEMs
BENDIX
- 5014482
- 5014428
- 5012532
- 5011441
- 5011427
- 5010806
- 5010803
CATERPILLAR
- 2554160
- 2233637
- 2233636
- 1916521
- 10R1437
- 0R1624
- 0R1623
- 255-4160
- 223-3637
- 223-3636
- 191-6521
- 10R-1437
- 0R-1624
- 0R-1623
Related Products
Repair Kits
Vehicles Used
| Brand | Model | Model Type | Engine |
|---|---|---|---|
| BENDIX | |||
| CATERPILLAR |
FAQ
What are the compatible OEM part numbers for this unit?
This product is compatible with the following OEM numbers: BENDIX 5010803, 501 own code stays original, 5011427, 5011441, 5012532, 5014428, 5014482, CATERPILLAR 0R1623, 0R1624, 10R1437, 1916521, 2233636, 2233637, and 255416 actually refers to the part type.
Which vehicle systems can this air compressor serve?
This single cylinder air compressor is designed specifically for systems manufactured by BENDIX and CATERPILLAR to maintain stable air pressure.
What are the cooling requirements for this compressor?
The unit is designed as a water-cooled (W) component to ensure optimal temperature regulation during operation in demanding environments.
Does this unit include an unloader port?
Yes, the component features a standard air unloader port with a size of 1/8”-27 NPT for integrated pneumatic control.
How can I ensure correct fitment for my heavy-duty vehicle?
Technicians should verify the cylinder bore (Ø92.0) and the specific port configurations (Air Inlet/Outlet) against the existing part to ensure a perfect match.
