2200 020 002 Single Cylinder, Air Compressor

Name: 2200 020 002 Single Cylinder, Air Compressor
Brand: Vaden Original
SKU: 2200 020 002

2200 020 002

Summary

●Cylinder Bore: Ø92.00 ●Stroke: 54 mm ●Swept Volume: 360cm³ ●Air Inlet Port: 7/8’’-14 UNF ●Air Outlet Port: 3/16’’-12 UN ●Number of Cylinders: 1 ●Through Drive: ✓ ●Air Unloader Port: 1/8”-27 NPT ●Water (W) or Air (A) Cooled: W ●Water Inlet Port: 3/4’’-16 UNF ●Water Outlet Port: 3/4’’-16 UNF ●With ESS Feature: ✓ ●Water Cooled Valve Plate: ✓ ●Weight: 22,6 KG

EAN Code	8699031068695

Ready to Order

Get Information

Compatible OEM Codes

CATERPILLAR 255-4160 223-3637 223-3636 191-6521 10R-1437 0R-1624 0R-1623
BENDIX 5014482 5014428 5012532 5011441 5011427 5010806 5010803

Description

This VADEN ORIGINAL product, code 2200 020 002, belongs to the Single Cylinder, Air Compressor group and is an equivalent for the original CATERPILLAR (0R1623, 0R1624, 10R1437, 1916521, 2233636, 2233637, 2554160), BENDIX (5010803, 5010806, 5011427, 5011441, 5012532, 5014428, 5014482) numbers. Manufactured to OE-quality standards, it delivers performance equivalent to the original at an affordable price.

Technical Specifications

Cylinder Bore	Ø92.00
Stroke	54 mm
Swept Volume	360cm³
Air Inlet Port	7/8’’-14 UNF
Air Outlet Port	3/16’’-12 UN
Number of Cylinders	1
Through Drive	OK
Air Unloader Port	1/8”-27 NPT
Water (W) or Air (A) Cooled	W
Water Inlet Port	3/4’’-16 UNF
Water Outlet Port	3/4’’-16 UNF
With ESS Feature	OK
Water Cooled Valve Plate	OK
Weight	22,6 KG
